Littelfuse MC Multiport Series MS-013 - Manual

SIDACtor ® Protection Thyristors
67
Revised: February 22, 2011
© 2011 Littelfuse, Inc.
Specifications are subject to change without notice.
Please refer to www.littelfuse.com for current information.
Broadband Optimized ™ Protection
MC Multiport Series - MS-013
Electrical Characteristics
MC Multiport Series MS-013 are low capacitance
SIDACtor
® devices designed to protect broadband
equipment from damaging overvoltage transients.
The series provides a dual port surface mount solution
that enables equipment to comply with various global
regulatory standards while limiting the impact to
broadband signals.
1
(R
1
)
2 (G
1
)
3
(T
1
) 6 (T
2
)
4 (R
2
)
5 (G
2
)
Description
Agency Approvals
Agency Agency File Number
E133083
Schematic Symbol
Pinout Designation
Applicable Global Standards
Features and Benefits
t Low voltage overshoot
t Low on-state voltage
t Does not degrade with
use
t Fails short circuit when
surged in excess of
ratings
t Two-pair protection
t 40% lower capacitance
than our Baseband
Protectors, for
applications that
demand greater signal
integrity
t Replaces four discrete
devices
Part Number Marking
V
DRM
@l
DRM
=5μA
V
S
@100V/μs
V
DRM
@l
DRM
=5μA
V
S
@100V/μs
I
H
I
S
I
T
V
T
@I
T
= 2.2
Amps
Capacitance
V V V V
mA min mA max A max V max
Pins 1-2, 3-2, 4-5, 6-5 Pins 1-3, 4-6
P0084UCMCLxx P0084UCMC 6 25 12 50 50 800 2.2 8
See
Capaci-
tance Val-
ues Table
P0304UCMCLxx P0304UCMC 25 40 50 80 50 800 2.2 8
P0644UCMCLxx P0644UCMC 58 77 116 154 150 800 2.2 8
P0724UCMCLxx P0724UCMC 65 88 130 176 150 800 2.2 8
P0904UCMCLxx P0904UCMC 75 98 150 196 150 800 2.2 8
P1104UCMCLxx P1104UCMC 90 130 180 260 150 800 2.2 8
P1304UCMCLxx P1304UCMC 120 160 240 320 150 800 2.2 8
1
2
3
6
5
4
t TIA-968-A
t TIA-968-B
t ITU K.20/21 Enhanced
Level
t ITU K.20/21 Basic Level
t GR 1089 Inter-building
t GR 1089 Intra-building
t IEC 61000-4-5
t YD/T 1082
t YD/T 993
t YD/T 950
Notes:
- Absolute maximum ratings measured at T
A
= 25ºC (unless otherwise noted).
- Devices are bi-directional (unless otherwise noted).
- XX Part Number Suffix: ‘TP’ (Tube Pack) or ‘RP’ (Reel Pack).
Table continues on next page.
