R-RATED MEDIUM VOLTAGE FUSES
Current-Limiting
R
RATED
SySTEM/
CATALOG
NUMBER
SIzE
MAxIMUM
CONTINUOUS
CURRENT @
40 DEGREES C°
DIM. A
(INChES)
DIM. B
(INChES)
MINIMUM
INTERRUPTING
RATING RMS
AMPS
MAxIMUM
INTERRUPTING
RATING RMS
(ASyM)
FIGURE
NUMBER
5.5 KV
702R1C5.5
2R
70
12"
15.875"
170
80,000
1
1003R1C5.5
3R
100
12"
15.875"
250
80,000
1
1304R1C5.5
4R
130
12"
15.875"
340
80,000
1
1505R1C5.5
5R
150
12"
15.875"
390
80,000
1
1706R1C5.5
6R
170
12"
15.875"
500
80,000
1
2009R1C5.5
9R
200
12"
15.875"
760
80,000
1
23012R1C5.5
12R
230
12"
15.875"
1000
80,000
1
39018R2C5.5
18R
390
12"
15.875"
1500
80,000
2
45024R2C5.5
24R
450
12"
15.875"
1950
80,000
2
48026R2C5.5
26R
480
12"
15.875"
2100
80,000
2
55030R2C5.5
30R
550
12"
15.875"
2400
80,000
2
60032R2C5.5
32R
600
12"
15.875"
2600
80,000
2
65036R2C5.5
36R
650
12"
15.875"
2900
80,000
2
55030R3C5.5
30R
550
12"
15.875"
2400
80,000
3
60032R3C5.5
32R
600
12"
15.875"
2600
80,000
3
65036R3C5.5
36R
650
12"
15.875"
2900
80,000
3
R
RATED
SySTEM/
CATALOG
NUMBER
SIzE
MAxIMUM
CONTINUOUS
CURRENT @
40 DEGREES C°
DIM. A
(INChES)
DIM. B
(INChES)
MINIMUM
INTERRUPTING
RATING RMS
AMPS
MAxIMUM
INTERRUPTING
RATING RMS
(ASyM)
FIGURE
NUMBER
8.25 KV
702R1C8.25
2R
70
12"
15.875"
190
80,000
1
1003R1C8.25
3R
100
12"
15.875"
225
80,000
1
1304R1C8.25
4R
130
12"
15.875"
330
80,000
1
1505R1C8.25
5R
150
12"
15.875"
440
80,000
1
1706R1C8.25
6R
170
12"
15.875"
500
80,000
1
2009R1C8.25
9R
200
12"
15.875"
740
80,000
1
23012R1C8.25
12R
230
12"
15.875"
955
80,000
1
39018R2C8.25
18R
390
12"
15.875"
1440
80,000
2
45024R2C8.25
24R
450
12"
15.875"
1910
80,000
2
For hookeye attachment; add “W” suffix to part number
R
RATED
SySTEM/
CATALOG
NUMBER
SIzE
MAxIMUM
CONTINUOUS
CURRENT @
40 DEGREES C°
DIM. A
(INChES)
DIM. B
(INChES)
MINIMUM
INTERRUPTING
RATING RMS
AMPS
MAxIMUM
INTERRUPTING
RATING RMS
(ASyM)
FIGURE
NUMBER
5.5 KV
14”C
LIP
C
ENTERS
702R1C5.5X
2R
70
14"
17.875"
170
80,000
1
1003R1C5.5X
3R
100
14"
17.875"
250
80,000
1
1304R1C5.5X
4R
130
14"
17.875"
340
80,000
1
1505R1C5.5X
5R
150
14"
17.875"
390
80,000
1
1706R1C5.5X
6R
170
14"
17.875"
500
80,000
1
2009R1C5.5X
9R
200
14"
17.875"
760
80,000
1
23012R1C5.5X
12R
230
14"
17.875"
1000
80,000
1
39018R2C5.5X
18R
390
14"
17.875"
1500
80,000
2
45024R2C5.5X
24R
450
14"
17.875"
1950
80,000
2
55030R2C5.5X
30R
550
14”
17.875”
2400
80,000
2
R
RATED
SySTEM/
CATALOG
NUMBER
SIzE
MAxIMUM
CONTINUOUS
CURRENT @
40 DEGREES C°
DIM. A
(INChES)
DIM. B
(INChES)
MINIMUM
INTERRUPTING
RATING RMS
AMPS
MAxIMUM
INTERRUPTING
RATING RMS
(ASyM)
FIGURE
NUMBER
2.
75 K
V
702R1C2.75
2R
70
7"
10.875"
170
80,000
1
1003R1C2.75
3R
100
7"
10.875"
250
80,000
1
1304R1C2.75
4R
130
7"
10.875"
340
80,000
1
1505R1C2.75
5R
150
7"
10.875"
390
80,000
1
1706R1C2.75
6R
170
7"
10.875"
500
80,000
1
2009R1C2.75
9R
200
7"
10.875"
760
80,000
1
23012R1C2.75
12R
230
7"
10.875"
1000
80,000
1
39018R2C2.75
18R
390
7"
10.875"
1500
80,000
2
45024R2C2.75
24R
450
7"
10.875"
1950
80,000
2
