Page 10: Description

© JUNE 2011 Littelfuse POWR-GARD Products
www.littelfuse.com
POWR-GARD
®
Fuses—Medium Voltage
10
LIVE PARTS
TRIPLE BARREL
Bottom Lever In
Closed Position
.56 Dia. (2) Holes
For Mounting
Cable/Bus
.44 DIA. (2) HOLES
DOUBLE BARREL
SINGLE BARREL
1.75
1.00
2.00
2.00
2.00
4.9
4.85
3.63
3.63
3.75
Top Lever in
Open Position
A
Blown Fuse
Indicator
TOP
VIEW
4.50
3.08
1.50
4.16
.038" HOLES
.78
.63
.08
.30
.31
.08
.71
1.15
.05
.78
Description
Live parts are available for mounting E, R, and PT single, double, and triple barrel fuses.
Mounting clips are available for ferrule type and clip lock style fuses.
All clips are sold in pairs.
Part Number: 700-520-CL
System Number: 0700520.ZXCL
Clip Lock Design
Part Number: 700-530
System Number: 0700530.Z
For use with all 3" diameter fuses.
Dimensions for reference only.
Part Number: 700-500
System Number: 0700500.Z
For use with all
13
/
16
" (.8125”) diameter PT fuses
Mounting Details for Clip Lock
Dimensions in inches
Part Number: 700-156
System Number: 0700156.Z
For use with 1
9
/
16
" to 1
5
/
8
” (1.625”) diameter PT fuses.
Part Number: 700-300
System Number: 0700300.Z
For use with 3" diameter fuses.
2.85
2.00
3.74
Dimensions in inches
Dimensions in inches
Dimensions in inches
Dimensions in inches
