Littelfuse SIDACtor Series SMA - Manual (Page 4)

SIDACtor ® Protection Thyristors
4
Revised: March 2, 2012
© 2012 Littelfuse, Inc.
Specifications are subject to change without notice.
Please refer to www.littelfuse.com for current information.
Baseband Protection (Voice-DS1)
Part Marking Part Numbering
Package Type Description
Packing Options
Quantity
Added Suffix Industry Standard
S1
DO-214AC
Tape & Reel Pack
12mm/13” tape
5000 RP EIA-481
Packing Options
Pxxx
Date Code
Part Marking Code
(Refer to Electrical Characteristics Table)
xxxxx
CONSTRUCTION
VARIABLE
REEL PACK
I
PP
RATING
RoHS COMPLIANT
TYPE
P = SIDACtor
P A L RP
MEDIAN VOLTAGE
PACKAGE TYPE
xxx 0 S1
Dimensions
Inches Millimeters
Min Max Min Max
A 0.049 0.065 1.250 1.650
B 0.157 0.177 3.990 4.500
C 0.100 0.110 2.540 2.790
D 0.078 0.090 1.980 2.290
E 0.030 0.060 0.780 1.520
F - 0.008 - 0.203
G 0.194 0.208 4.930 5.280
H 0.006 0.012 0.152 0.305
I 0.070 - 1.800 -
J 0.082 - 2.100 -
K - 0.090 - 2.300
L 0.082 - 2.100 -
DO-214AC (SMA)
A
D
E
G
F
H
C
B
(all dimensions in mm)
I
L K J
Solder Pads
Dimensions
0.47
(12.0)
0.157
(4.0)
0.157
(4.0)
0.49
(12.5)
0.80 (20.2)
Arbor Hole Dia.
13.0 (330)
Dimensions are in inches
(and millimeters).
Direction of Feed
0.059 DIA
(1.5)
Cover tape
Tape and Reel Specification — DO-214AC
