Littelfuse BLN Series User Manual
Cartridge and axial lead fuses, Bln series, Fibre body fast-acting type > bln series

15
Cartridge and Axial Lead Fuses
©2009 Littelfuse, Inc.
Specifications are subject to change without notice.
Revised: February 18, 2009
BLN Series
Fibre Body Fast-Acting Type > BLN Series
Please refer to www.littelfuse.com/series/BLN.html for current information.
Agency Approvals
Electrical Characteristics for Series
Pb
Agency
Agency File Number
Ampere Range
E10480
1.0 - 30A
®
LR2 9862
1.0 - 30A
PS
E
NBK170305-E10480A-D
1.0 - 30A
Electrical Characteristics
Ordering
Number
Amp
Rating
(A)
Max
Voltage
Rating
(V)
Interrupting
Rating
Nominal
Cold
Resistance
(Ohms)
Agency Approvals
PS
E
BLN 001
1
250
10,000
amperes at
250 VAC.
.395
x
x
x
BLN 01.5
1.5
.222
x
x
x
BLN 002
2
.125
x
x
x
BLN 003
3
.0645
x
x
x
BLN 004
4
.0432
x
x
x
BLN 005
5
.0413
x
x
x
BLN 006.
6
.0284
x
x
x
BLN 008
8
.0166
x
x
x
BLN 010
10
.011
x
x
x
BLN 012
12
.00920
x
x
x
BLN 015
15
.00684
x
x
x
BLN 020
20
.0036
x
x
x
BLN 025
25
.00360
x
x
x
BLN 030
30
.00270
x
x
x
Electrical Specifications by Item
®
Fibertube, 250 V BLN Fuses provide low-cost protection for
military applications and control circuits.
% of Ampere
Rating
Ampere Rating
Opening Time
100%
0-30
Until temp stabilizes
135%
0–30
1 hours, Maximum
200%
0-30
2 minutes, Maximum
Description
BLN Series
Fibre Body Fast-acting Midget / 5AG Size Fuse
PS
E
