Square body Semiconductor FuSeS
700/1300 VAC • Very Fast-Acting • 63-2500 A
Dimensions for reference only.
catalog number
dimenSionS incheS (mm)
a b c d e F g h J
LA130URD70LI (63-315)
LA120URD70LI (350)
1.57
(40)
0.98
(25)
0.49
(12.5)
0.83
(21)
0.71
(18)
3.60
(91.4)
5.13
(130.4)
6.00
(152.4)
0.41
(10.5)
LA130URD71LLI (160-450)
LA120URD71LLI (500-550)
LA110URD71LLI (630)
2.01
(51)
0.98
(25)
0.49
(12.5)
1.0
(26.5)
0.89
(22.5)
3.60
(91.4)
5.13
(130.4)
6.00
(152.4)
0.57
(14.6)
LA130URD72LI (280-550)
LA120URD72LI (800)
LA110URD72LI (700-800)
2.36
(60)
1.26
(32)
0.63
(16)
1.18
(30)
1.06
(27)
3.84
(97.6)
5.2
(132.4)
6.20
(157.4)
0.57
(14.6)
LA130URD73LI (315-700)
LA120URD73LI (800)
LA110URD73LI (900-1000)
LA090URD73LI (1400)
LA070URD73LI (1600)
LA065URD73LI (1800)
2.93
(74.5)
1.57
(40)
0.79
(20)
1.46
(37.2)
1.35
(34.2)
3.89
(98.8)
5.21
(132.4)
6.20
(157.4)
0.63
(15.9)
catalog number
dimenSionS incheS (mm)
a b c
LA130URD70TTI (63-315)
LA120URD70TTI (350)
1.57
(40)
1.00
(26.4)
5 ⁄
16
-18 x 0.23 DP
LA130URD71TTI (160-450)
LA120URD71TTI (550-630)
2.01
(51)
1.19
(30.2)
5 ⁄
16
-18 x 0.36 DP
LA130URD72TTI (280-630)
LA120URD72TTI (700-800) 2.36
(60)
1.50
(38.1)
3 ⁄
8
-18 x 0.36 DP
LA130URD73TTI (315-900)
LA120URD73TTI (1000)
LA110URD73TTI (1250)
LA090URD73TTI (1400)
LA070URD73TTI (1600)
LA065URD73TTI (1800)
2.93
(74.5)
1.81
(46)
1 ⁄
2
-18 x 0.36 DP
Dimensions for reference only.
TYPES LI AND LLI
TYPE TTI
Dimensions
Dimensions
North American Flat Single Hole, Type TTI
North American Straight Blade, Types LI and LLI
