Littelfuse LAxxxURD Series Square body - Manual (Page 4)

POWR-GARD ® Fuse Datasheet
Littelfuse.com © 2013 Littelfuse POWR-GARD ® Products
Rev: 031513
4 of 5
Square body Semiconductor FuSeS
700/1300 VAC • Very Fast-Acting • 63-2500 A
body
Size
ampere
rating
rated
Voltage
melting i 2 t
(a 2 S x 10 3 )
total i 2 t
@ rated
Voltage
(a 2 S x 10 3 )
*WattS loSS @
rated current
(W)
long blade
catalog number
type li/lli
tapped terminal
catalog number
type tti
70
63 1300 0.21 1.8 26 LA130URD70LI0063 LA130URD70TTI0063
80 1300 0.47 4 27 LA130URD70LI0080 LA130URD70TTI0080
100 1300 0.83 7.2 30 LA130URD70LI0100 LA130URD70TTI0100
125 1300 1.3 11 38 LA130URD70LI0125 LA130URD70TTI0125
160 1300 2.5 22 45 LA130URD70LI0160 LA130URD70TTI0160
200 1300 4.7 40 54 ⁄ 56 LA130URD70LI0200 LA130URD70TTI0200
250 1300 9.6 82 58 ⁄ 61 LA130URD70LI0250 LA130URD70TTI0250
315 1300 20 172 66 ⁄ 72 LA130URD70LI0315 LA130URD70TTI0315
350 1200 28 205 68 ⁄ 75 LA120URD70LI0350 LA120URD70TTI0350
71
160 1300 2.6 22 46 LA130URD71LLI0160 LA130URDT1TTI0160
200 1300 4.7 40 54 LA130URD71LLI0200 LA130URD71TTI0200
250 1300 8.9 76 61 LA130URD71LLI0250 LA130URD71TTI0250
280 1300 12 102 68 ⁄ 70 LA130URD71IL0280 LA130URD71TTI0280
315 1300 16 138 73 ⁄ 76 LA130URD71LLI0315 LA130URD71TTI0315
350 1300 22 190 76 ⁄ 80 LA130URD71LLI0350 LA130URD71TTI0350
400 1300 38 330 76 ⁄ 80 LA130URD71LLI0400 LA130URD71TTI0400
450 1300 47 405 87 ⁄ 95 LA130URD71LLI0450 LA130URD71TTI0450
500 1200 68 500 90 ⁄ 100 LA120URD71LLI0500 LA120URD71TTI0500
550 1200 84 620 98 ⁄ 112 LA120URD71LLI0550 LA120URD71TTI0550
630 1100 125 930 105 LA110URD71LLI0630 –
630 1200 125 930 120 – LA120URD71TTI0630
72
280 1300 10 90 72 LA130URD72LI0280 LA130URD72TTI0280
315 1300 15 130 76 LA130URD72LI0315 LA130URD72TTI0315
350 1300 21 180 77 LA130URD72LI0350 LA130URD72TTI0350
400 1300 32 285 80 LA130URD72LI0400 LA130URD72TTI0400
450 1300 44 380 87 ⁄ 89 LA130URD72LI0450 LA130URD72TTI0450
500 1300 57 500 94 ⁄ 98 LA130URD72LI0500 LA130URD72TTI0500
550 1300 68 590 110 ⁄ 120 LA130URD72LI0550 LA130URD72TTI0550
630 1200 105 920 113 LA120URD72LI0630 –
630 1300 105 920 125 – LA130URD72TTI0630
700 1100 145 1040 122 LA110URD72LI0700 –
700 1200 145 1040 140 – LA120URD72TTI0700
800 1100 215 1590 125 LA110URD72LI0800 –
800 1200 215 1590 146 – LA120URD72TTI0800
73
315 1300 12 102 84 LA130URD73LI0315 LA130URD73TTI0315
350 1300 17 150 86 LA130URD73LI0350 LA130URD73TTI0350
400 1300 25 220 93 LA130URD73LI0400 LA130URD73TTI0400
450 1300 35 310 99 ⁄ 100 LA130URD73LI0450 LA130URD73TTI0450
500 1300 44 390 110 ⁄ 112 LA130URD73LI0500 LA130URD73TTI0500
550 1300 57 500 116 ⁄ 120 LA130URD73LI0550 LA130URD73TTI0550
630 1300 84 730 125 ⁄ 132 LA130URD73LI0630 LA130URD73TTI0630
700 1300 110 960 135 ⁄ 146 LA130URD73LI0700 LA130URD73TTI0700
800 1200 190 1630 136 LA120URD73LI0800 –
800 1300 190 1630 148 – LA130URD73TTI0800
900 1100 250 2160 150 LA110URD73LI0900 –
900 1000 250 2160 170 – LA100URD73TTI0900
1000 1000 370 2430 152 ⁄ 174 LA100URD73LI1000 LA100URD73TTI1000
1100 1000 445 2580 168 ⁄ 208 LA100URD73LI1100 LA100URD73TTI1100
1250 1000 585 3480 186 ⁄ 200 LA100URD73LI1250 LA100URD73TTI1250
1400 900 755 3880 210 ⁄ 228 LA090URD73LI1400 LA090URD73TTI1400
1600 700 1430 5630 203 LA070URD73LI1600 LA070URD73TTI1600
1800 660 2040 7600 206 LA065URD73LI1800 LA065URD73TTI1800
*Watts loss data is published for both blade and tapped style mounting configurations.
When two watts loss values are shown, this represents tapped/blade values respectively.
Contact Littelfuse for characteristic curves.
