SL1011A/B and SL1411A Series
SL1011A/B and SL1411A Series
Packaging Dimensions
For 'A' Type Axial Lead Items
For 'SM' Type Surface Mount Items (SL1411A series only)
For 'C' Type Core Items: Packed in plastic bag (500 pcs)
22.8
[0.898]
52.4 +2
–1
[2.063 ]
+0.079
–0.039
6 ± 1
[0.236 ± 0.039]
< 0.7 Max.
< 1.2 Max. Lead Bend
10 ± 0.5 Pitch
[0.394 ± 0.020]
16 +0.3 / -0.1
[0.630 +0.012 / -0.004]
7.5 ± 0.1
[0.295 ± 0.004]
8.5 ± 0.1
[0.335 ± 0.004]
1.75 ± 0.1
[0.069 ± 0.004] 1.5 DIA. MAX.
[0.059]
1.5 DIA. MAX.
[0.059] 12 ± 0.1
[0.472 ± 0.004]
8.6 ± 0.1
[0.339 ± 0.004]
0.4 ± 0.05
[0.016 ± 0.002]
10x4 ± 0.1 = 40 ± 0.2
[10x0.157 ± 0.004 = 1.575 ± 0.008]
4 ± 0.1
[0.157 ± 0.004]
Direction of Feed
17.7
[0.697]
275.0
[ 10.83 ]
100.0
[ 3.94 ]
25.0
[ 0.98 ]
76.0
[ 2.99 ]
Direction of Feed
254.0 - 356.0
[10.0 - 14.0]
77.0 Max.
[3.03]
Dimensions are in millimeters [and inches]
Dimensions are in millimeters [and inches] Dimensions are in millimeters [and inches]
Dimensions are in millimeters [and inches]
