Gas Discharge Tube (GDT) Products
49
Revised: June 28, 2010
Specifications are subject to change without notice.
Please refer to www.littelfuse.com for current information.
Customer should verify actual device performance in their specific applications.
SL1011A/B and SL1411A Series
SL1011A/B and SL1411A Series
Device Dimensions
6.05 ± 0.2
[0.238 ± 0.0079]
5.55 [0.219]
8.3 ± 0.1
Ш9.30 ± 0.2
Ш8.3 ± 0.1
5
0.5 ± 0.1
4 [0.157]
7.00 [0.276]
1.30 [0.051]
5.40 [0.213]
TOP VIEW PROFILE VIEW SEMI–PROFILE VIEW
SOLDER PAD LAYOUT
'SM' Type Surface Mount Devices 'A' Type Axial Lead Devices
'A' Type Axial Lead Devices
For SL1011A/SL1011B series:
For SL1411A series:
'C' Type Core Devices
Ш8.0
+ 0.10
– 0.30
[0.315 ] + 0.0039
– 0.0118
6.05 ± 0.2
Ш1.0
[0.039]
62 ± 2
[0.238 ± 0.0079]
TOP VIEW PROFILE VIEW
Ш8.0 ± 0.2
[0.315 ± 0.0079]
6.05 ± 0.2
Ш0.8
[0.031]
62 ± 2
[0.238 ± 0.0079]
TOP VIEW PROFILE VIEW
TOP VIEW PROFILE VIEW SEMI–PROFILE VIEW
Ш8.00
+ 0.10
– 0.30
Ш8.00
+ 0.10 – 0.30
[0.315 ]
+ 0.0039
– 0.0118
6.05
+ 0.20
– 0.15
[0.238 ]
+ 0.0079
– 0.0059
'C' Type Core Devices
6.05 ± 0.2
[0.238 ± 0.0079]
Ш8.0 ± 0.2
[0.315 ± 0.0079]
Ш8.0 ± 0.2
TOP VIEW PROFILE VIEW SEMI–PROFILE VIEW
