TVS Diode Arrays
(SPA
®
Diodes)
Revision: November 29, 2012
SP6003 Series
ESD and EMI Filter Devices - SP6003 Series
CAUTION: Stresses above those listed in “Absolute Maximum Ratings” may cause
permanent damage to the device. This is a stress only rating and operation of the device
at these or any other conditions above those indicated in the operational sections of this
specification is not implied.
Absolute Maximum Ratings
Symbol
Parameter
Value
Units
T
OP
Operating Temperature
-40 to 125
°C
T
STOR
Storage Temperature
-55 to 150
°C
Thermal Information
Parameter
Rating
Units
Storage Temperature Range
-55 to 150
°C
Maximum Junction Temperature
150
°C
Maximum Lead Temperature (Soldering 10s)
260
°C
Electrical Characteristics
(T
OP
=25ºC)
Parameter
Symbol
Test Conditions
Min
Typ
Max
Units
Reverse Standoff Voltage
V
RWM
5.0
V
Breakdown Voltage
V
BR
I
R
=1mA
7.0
V
Reverse Leakage Current
I
LEAK
V
RWM
=5V
0.1
1.0
µA
Resistance
R
A
I
R
=10mA
80
100
120
Ω
Diode Capacitance
1,2
C
D
V
R
=2.5V,f=1MHz
7
pF
Line Capacitance
1,2
C
L
V
R
=2.5V,f=1MHz
11
14
17
pF
ESD Withstand Voltage
1
V
ESD
IEC61000-4-2 (Contact Discharge)
±12
kV
IEC61000-4-2 (Air Discharge)
±15
kV
Cutoff Frequency
3
F
-3dB
Above this frequency, appreciable
attenutation occurs
250
MHz
Notes:
1
Parameter is guaranteed by design and/or device characterization.
2
Total line capacitance is two times the diode capacitance (C
D
).
3
50Ω source and 50Ω load termination
Analog Crosstalk (S41)
Insertion Loss (S21)
10
100
1000
Frequency (MHz)
-50
-40
-30
-35
-45
-20
-25
-10
-5
0
-15
A
tte
nua
tion
(d
B)
10
100
1000
Frequency (MHz)
-120
-90
-105
-135
-60
-75
-30
-15
0
-45
At
te
nuat
io
n
(d
B)
