Teccor ® brand Thyristors
35 Amp Standard & 30 / 35 Amp Alternistor (High Commutation) Triacs
Qxx30xHx & Qxx35xx & Qxx35xHx Series
Symbol Test Conditions Quadrant Qxx35P5 Unit
I
GT
V
D
= 12V R
L
= 30 :
*o**o*** MAX. 50
mA
IV TYP. 120
V
GT
*o**o*** MAX. 2.75 V
V
GD
V
D
= V
DRM
R
L
= 3.3 k : T
J
= 110°C ALL MIN. 0.2 V
I
H
I
T
= 400mA MAX. 50 mA
dv/dt V
D
= V
DRM
Gate Open T
J
= 125°C
600V
MIN.
475
V/μs
800V 400
(dv/dt)c (di/dt)c = 18.9 A/ms T
J
= 125°C TYP. 5 V/μs
t
gt
I
G
= 2 x I
GT
PW = 15μs I
T
= 49.5A(pk) TYP. 3 μs
Absolute Maximum Ratings — Alternistor Triac (3 Quadrants)
Symbol Parameter Value Unit
I
T(RMS)
RMS on-state current (full sine wave)
Qxx35RH5/Qxx35NH5 T
C
= 90°C 35
A
Qxx30LH5/Qxx30LH3 T
C
= 50°C 30
I
TSM
Non repetitive surge peak on-state current
(full cycle, T
J
initial = 25°C)
f = 50 Hz t = 20 ms 290
A
f = 60 Hz t = 16.7 ms 350
I 2 t I 2 t Value for fusing t
p
= 8.3 ms 508 A 2 s
di/dt
Critical rate of rise of on-state current
(I
G
= 200mA with d 0.1μs rise time)
f = 120 Hz T
J
= 125°C 100 A/μs
I
GTM
Peak gate trigger current t
p
d 10 μs I
GT
d I
GTM
T
J
= 125°C 2 A
P
G(AV)
Average gate power dissipation T
J
= 125°C 0.5 W
T
stg
Storage temperature range -40 to 150 °C
T
J
Operating junction temperature range -25 to 125 °C
Electrical Characteristics (T
J
= 25°C, unless otherwise specified) —Standard Triac
Symbol Test Conditions Quadrant
Qxx35RH5
Qxx35NH5
Qxx30LH5
Qxx30LH3 Unit
I
GT
V
D
= 12V R
L
= 30 :
*o**o*** MAX. 50 25 mA
V
GT
*o**o*** MAX. 2 2 V
V
GD
V
D
= V
DRM
R
L
= 3.3 k : T
J
= 125°C *o**o*** MIN. 0.2 0.2 V
I
H
I
T
= 400mA MAX. 75 40 mA
dv/dt V
D
= V
DRM
Gate Open T
J
= 125°C
400V
MIN.
475 350
V/μs
600V 400 250
(dv/dt)c (di/dt)c = 18.9 A/ms T
J
= 125°C MIN. 20 10 V/μs
t
gt
35A device
I
G
= 2 x I
GT
PW = 15μs I
T
= 49.5A(pk)
TYP. 3 3 μs
30A device
I
G
= 2 x I
GT
PW = 15μs I
T
= 42.4A(pk)
Note: xx = voltage
Electrical Characteristics (T
J
= 25°C, unless otherwise specified) — Alternistor Triac (3 Quadrants)
