Surface Mount Fuses
NANO 2® > 250V UMF Time Lag > 465 Series
Average Time Current Curves
100
100
10
1
0.1
0.01
0.001
1 10 1000 0.1
1
A
1.25
A
1.6
A
2
A
2.5
A
3.15
A
TIME IN SECONDS
CURRENT IN AMPERES
4
A
5
A
6.3
A
Soldering Parameters
Temperature Rerating Curve
Reflow Condition Pb – Free assembly
pre Heat
- Temperature min (T
s(min)
) 150°C
- Temperature max (T
s(max)
) 200°C
- Time (min to max) (t
s
) 60 – 120 secs
Average ramp up rate (liquidus Temp
(T
l
) to peak
5°C/second max.
T
S(max)
to T
l
- Ramp-up Rate 5°C/second max.
Reflow
- Temperature (T
l
) (liquidus) 217°C
- Temperature (t
l
) 60 – 90 seconds
peak Temperature (T
p
) 260 +0/–5 °C
Time within 5°C of actual peak
Temperature (t
p
)
20 – 40 seconds
Ramp-down Rate 5°C/second max.
Time 25°C to peak Temperature (T
p
) 8 minutes max.
Do not exceed 260°C
Wave Soldering parameters
260°C Peak
Temperature,
3 seconds max.
Note:
1. Derating depicted in this curve is in addition to the standard derating of 15% for
continuous operation.
Time
Te
mperatur
e
T
P
T
L
T
S(max)
T
S(min)
25
t
P
t
L
t
S
time to peak temperature
(t 25ºC to peak)
Ramp-down
Ramp-up
Preheat
Critical Zone
T L to T P
