Transient Voltage Suppression Diodes
© 2014 Littelfuse, Inc.
Specifications are subject to change without notice.
Revised: 01/24/14
Axial Leaded – 600W > P6KE series
Part Numbering System
OPTION CODE:
BLANK Reel Tape
-B Bulk Packaging
SERIES CODE
P6KE xxx XXX
TYPE CODE:
A Uni-Directional (5% V
BR
Voltage Tolerance)
CA Bi-Directional (5%
V
BR
Voltage Tolerance)
V
BR
VOLTAGE CODE
(Refer to the Electrical Characteristics table)
Part Marking System
F
P6KEXXX
YYWW
Trace Code Marking
YY:Year Code
WW: Week Code
Product Type
Littelfuse Logo
Cathode Band
(for uni-directional
products only)
Packaging
Part Number
Component Package
Quantity
Packaging Option
Packaging Specification
P6KExxxXX
DO-204AC
4000
Tape & Reel
EIA STD RS-296
P6KExxxXX-B
DO-204AC
1000
BULK
Littelfuse Spec.
Tape and Reel Specification
2.063+0.079/-0.039
2.56
0.197+/-0.020
2.75
0.047
(330.2)
Recess Depth Max. 0.75 (19.05)
Off Center
either side
0.028(0.7)
Dimensions are in
inches/mm
0.236
(65.0)
(5.0+/- 0.5)
(53.0+2.0/-1.0)
(6.0)
(1.2)
(69.85)
13.0
(76.2)
3.0
0.68
(17.27)
Direction of Feed
