Littelfuse P6KE Series - Manual (Page 2)

Transient Voltage Suppression Diodes
© 2014 Littelfuse, Inc.
Specifications are subject to change without notice.
Revised: 01/24/14
Axial Leaded – 600W > P6KE series
Electrical Characteristics
(T
A
=25°C unless otherwise noted)
Part
Number
(Uni)
Part
Number
(Bi)
Reverse
Stand off
Voltage V
R
(Volts)
Breakdown
Voltage V
BR
(Volts) @ I
T
Test
Current
I
T
(mA)
Maximum
Clamping
Voltage
V
C
@ I
pp
(V)
Maximum
Peak
Pulse
Current I
pp
(A)
Maximum
Reverse
Leakage
I
R
@ V
R
(µA)
Agency
Approval
MIN MAX
P6KE6.8A P6KE6.8CA 5.80 6.45 7.14 10 10.5 58.1 1000 X
P6KE7.5A P6KE7.5CA 6.40 7.13 7.88 10 11.3 54.0 500 X
P6KE8.2A P6KE8.2CA 7.02 7.79 8.61 10 12.1 50.4 200 X
P6KE9.1A P6KE9.1CA 7.78 8.65 9.55 1 13.4 45.5 50 X
P6KE10A P6KE10CA 8.55 9.50 10.50 1 14.5 42.1 10 X
P6KE11A P6KE11CA 9.40 10.50 11.60 1 15.6 39.1 5 X
P6KE12A P6KE12CA 10.20 11.40 12.60 1 16.7 36.5 5 X
P6KE13A P6KE13CA 11.10 12.40 13.70 1 18.2 33.5 1 X
P6KE15A P6KE15CA 12.80 14.30 15.80 1 21.2 28.8 1 X
P6KE16A P6KE16CA 13.60 15.20 16.80 1 22.5 27.1 1 X
P6KE18A P6KE18CA 15.30 17.10 18.90 1 25.2 24.2 1 X
P6KE20A P6KE20CA 17.10 19.00 21.00 1 27.7 22.0 1 X
P6KE22A P6KE22CA 18.80 20.90 23.10 1 30.6 19.9 1 X
P6KE24A P6KE24CA 20.50 22.80 25.20 1 33.2 18.4 1 X
P6KE27A P6KE27CA 23.10 25.70 28.40 1 37.5 16.3 1 X
P6KE30A P6KE30CA 25.60 28.50 31.50 1 41.4 14.7 1 X
P6KE33A P6KE33CA 28.20 31.40 34.70 1 45.7 13.3 1 X
P6KE36A P6KE36CA 30.80 34.20 37.80 1 49.9 12.2 1 X
P6KE39A P6KE39CA 33.30 37.10 41.00 1 53.9 11.3 1 X
P6KE43A P6KE43CA 36.80 40.90 45.20 1 59.3 10.3 1 X
P6KE47A P6KE47CA 40.20 44.70 49.40 1 64.8 9.4 1 X
P6KE51A P6KE51CA 43.60 48.50 53.60 1 70.1 8.7 1 X
P6KE56A P6KE56CA 47.80 53.20 58.80 1 77.0 7.9 1 X
P6KE62A P6KE62CA 53.00 58.90 65.10 1 85.0 7.2 1 X
P6KE68A P6KE68CA 58.10 64.60 71.40 1 92.0 6.6 1 X
P6KE75A P6KE75CA 64.10 71.30 78.80 1 103.0 5.9 1 X
P6KE82A P6KE82CA 70.10 77.90 86.10 1 113.0 5.4 1 X
P6KE91A P6KE91CA 77.80 86.50 95.50 1 125.0 4.9 1 X
P6KE100A P6KE100CA 85.50 95.00 105.00 1 137.0 4.5 1 X
P6KE110A P6KE110CA 94.00 105.00 116.00 1 152.0 4.0 1 X
P6KE120A P6KE120CA 102.00 114.00 126.00 1 165.0 3.7 1 X
P6KE130A P6KE130CA 111.00 124.00 137.00 1 179.0 3.4 1 X
P6KE150A P6KE150CA 128.00 143.00 158.00 1 207.0 2.9 1 X
P6KE160A P6KE160CA 136.00 152.00 168.00 1 219.0 2.8 1 X
P6KE170A P6KE170CA 145.00 162.00 179.00 1 234.0 2.6 1 X
P6KE180A P6KE180CA 154.00 171.00 189.00 1 246.0 2.5 1 X
P6KE200A P6KE200CA 171.00 190.00 210.00 1 274.0 2.2 1 X
P6KE220A P6KE220CA 185.00 209.00 231.00 1 328.0 1.9 1 X
P6KE250A P6KE250CA 214.00 237.00 263.00 1 344.0 1.8 1 X
P6KE300A P6KE300CA 256.00 285.00 315.00 1 414.0 1.5 1 X
P6KE350A P6KE350CA 300.00 332.00 368.00 1 482.0 1.3 1 X
P6KE400A P6KE400CA 342.00 380.00 420.00 1 548.0 1.1 1 X
P6KE440A P6KE440CA 376.00 418.00 462.00 1 602.0 1.0 1 X
P6KE480A P6KE480CA 408.00 456.00 504.00 1 658.0 0.9 1
P6KE510A P6KE510CA 434.00 485.00 535.00 1 698.0 0.9 1
P6KE530A P6KE530CA 477.00 503.50 556.50 1 725.0 0.8 1
P6KE540A P6KE540CA 486.00 513.00 567.00 1 740.0 0.8 1
P6KE550A P6KE550CA 495.00 522.50 577.50 1 760.0 0.8 1
P6KE600A P6KE600CA 512.00 570.00 630.00 1 828.0 0.75 1
For bidirectional type having V
R
of 10 volts and less, the I
R
limit is double.
For parts without A , the V
BR
is ± 10% and V
C
is 5% higher than with A parts
