Teccor ® brand Thyristors
4 Amp Sensitive & Standard Triacs
Lxx04xx & Qxx04xx Series
Packing Options
Part Number Marking Weight Packing Mode Base Quantity
L/Q004L/Ry/TP L/Qxx04L/Ry 2.2 g Bulk 500
L/Qxx04LyTP L/Qxx04Ly 2.2 g Tube 500 (50 per tube)
L/Qxx04DyRP L/Qxx04Dy 0.3 g Embossed Carrier 2500
L/Qxx04DyTP L/Qxx04Dy 0.3 g Tube Pack 750 (75 per tube)
L/Qxx04VyTP L/Qxx04Vy 0.4 g Tube Pack 750 (75 per tube)
Note: xx = Voltage; y = Sensitivity
Product Selector
Part Number
Voltage Gate Sensitivity Quadrants
Type Package
400V 600V 800V 1000V I – II – III IV
Lxx04L3 X X 3 mA 3 mA Sensitive Triac TO-220L
Lxx04D3 X X 3 mA 3 mA Sensitive Triac TO-252 D-PAK
Lxx04R3 X X 3mA 3mA Sensitive Triac TO-220R
Lxx04V3 X X 3 mA 3 mA Sensitive Triac TO-251 V-PAK
Lxx04L5 X X 5 mA 5 mA Sensitive Triac TO-220L
Lxx04D5 X X 5 mA 5 mA Sensitive Triac TO-252 D-PAK
Lxx04R5 X X 5mA 5mA Sensitive Triac TO-220R
Lxx04V5 X X 5 mA 5 mA Sensitive Triac TO-251 V-PAK
Lxx04L6 X X 5 mA 10 mA Sensitive Triac TO-220L
Lxx04D6 X X 5 mA 10 mA Sensitive Triac TO-252 D-PAK
Lxx04R6 X X 5mA 10mA Sensitive Triac TO-220R
Lxx04V6 X X 5 mA 10 mA Sensitive Triac TO-251 V-PAK
Lxx04L8 X X 10 mA 20 mA Sensitive Triac TO-220L
Lxx04D8 X X 10 mA 20 mA Sensitive Triac TO-252 D-PAK
Lxx04R8 X X 10mA 20mA Sensitive Triac TO-220R
Lxx04V8 X X 10 mA 20 mA Sensitive Triac TO-251 V-PAK
Qxx04L3 X X 10 mA Standard Triac TO-220L
Qxx04D3 X X 10 mA Standard Triac TO-252 D-PAK
Qxx04V3 X X 10 mA Standard Triac TO-251 V-PAK
Qxx04R3 X X 10mA Standard Triac TO-220R
Qxx04L4 X X X X 25 mA Standard Triac TO-220L
Qxx04D4 X X X X 25 mA Standard Triac TO-252 D-PAK
Qxx04R4 X X X X 25mA Standard Triac TO-220R
Qxx04V4 X X X X 25 mA Standard Triac TO-251 V-PAK
