Littelfuse SMDJ Series - Manual (Page 2)

Transient Voltage Suppression Diodes
© 2014 Littelfuse, Inc.
Specifications are subject to change without notice.
Revised: 01/24/14
Surface Mount – 3000W > SMDJ series
Electrical Characteristics
(T
A
=25°C unless otherwise noted)
Part
Number
(Uni)
Part
Number
(Bi)
Marking
Reverse
Stand off
Voltage
V
R
(Volts)
Breakdown
Voltage V
BR
(Volts) @ I
T
Test
Current
I
T
(mA)
Maximum
Clamping
Voltage V
C
@ I
pp
(V)
Maximum
Peak
Pulse
Current I
pp
(A)
Maximum
Reverse
Leakage I
R
@ V
R
(µA)
Agency
Approval
UNI BI MIN MAX
SMDJ5.0A SMDJ5.0CA RDE DDE 5.0 6.40 7.00 10 9.2 326.1 800 X
SMDJ6.0A SMDJ6.0CA RDG DDG 6.0 6.67 7.37 10 10.3 291.3 800 X
SMDJ6.5A SMDJ6.5CA RDK DDK 6.5 7.22 7.98 10 11.2 267.9 500 X
SMDJ7.0A SMDJ7.0CA PDM DDM 7.0 7.78 8.60 10 12.0 250.0 200 X
SMDJ7.5A SMDJ7.5CA PDP DDP 7.5 8.33 9.21 1 12.9 232.6 100 X
SMDJ8.0A SMDJ8.0CA PDR DDR 8.0 8.89 9.83 1 13.6 220.6 50 X
SMDJ8.5A SMDJ8.5CA PDT DDT 8.5 9.44 10.40 1 14.4 208.3 20 X
SMDJ9.0A SMDJ9.0CA PDV DDV 9.0 10.00 11.10 1 15.4 194.8 10 X
SMDJ10A SMDJ10CA PDX DDX 10.0 11.10 12.30 1 17.0 176.5 5 X
SMDJ11A SMDJ11CA PDZ DDZ 11.0 12.20 13.50 1 18.2 164.8 2 X
SMDJ12A SMDJ12CA PEE DEE 12.0 13.30 14.70 1 19.9 150.8 2 X
SMDJ13A SMDJ13CA PEG DEG 13.0 14.40 15.90 1 21.5 139.5 2 X
SMDJ14A SMDJ14CA PEK DEK 14.0 15.60 17.20 1 23.2 129.3 2 X
SMDJ15A SMDJ15CA PEM DEM 15.0 16.70 18.50 1 24.4 123.0 2 X
SMDJ16A SMDJ16CA PEP DEP 16.0 17.80 19.70 1 26.0 115.4 2 X
SMDJ17A SMDJ17CA PER DER 17.0 18.90 20.90 1 27.6 108.7 2 X
SMDJ18A SMDJ18CA PET DET 18.0 20.00 22.10 1 29.2 102.7 2 X
SMDJ20A SMDJ20CA PEV DEV 20.0 22.20 24.50 1 32.4 92.6 2 X
SMDJ22A SMDJ22CA PEX DEX 22.0 24.40 26.90 1 35.5 84.5 2 X
SMDJ24A SMDJ24CA PEZ DEZ 24.0 26.70 29.50 1 38.9 77.1 2 X
SMDJ26A SMDJ26CA PFE DFE 26.0 28.90 31.90 1 42.1 71.3 2 X
SMDJ28A SMDJ28CA PFG DFG 28.0 31.10 34.40 1 45.4 66.1 2 X
SMDJ30A SMDJ30CA PFK DFK 30.0 33.30 36.80 1 48.4 62.0 2 X
SMDJ33A SMDJ33CA PFM DFM 33.0 36.70 40.60 1 53.3 56.3 2 X
SMDJ36A SMDJ36CA PFP DFP 36.0 40.00 44.20 1 58.1 51.6 2 X
SMDJ40A SMDJ40CA PFR DFR 40.0 44.40 49.10 1 64.5 46.5 2 X
SMDJ43A SMDJ43CA PFT DFT 43.0 47.80 52.80 1 69.4 43.2 2 X
SMDJ45A SMDJ45CA PFV DFV 45.0 50.00 55.30 1 72.7 41.3 2 X
SMDJ48A SMDJ48CA PFX DFX 48.0 53.30 58.90 1 77.4 38.8 2 X
SMDJ51A SMDJ51CA PFZ DFZ 51.0 56.70 62.70 1 82.4 36.4 2 X
SMDJ54A SMDJ54CA RGE DGE 54.0 60.00 66.30 1 87.1 34.4 2 X
SMDJ58A SMDJ58CA PGG DGG 58.0 64.40 71.20 1 93.6 32.1 2 X
SMDJ60A SMDJ60CA PGK DGK 60.0 66.70 73.70 1 96.8 31.0 2 X
SMDJ64A SMDJ64CA PGM DGM 64.0 71.10 78.60 1 103.0 29.1 2 X
SMDJ70A SMDJ70CA PGP DGP 70.0 77.80 86.00 1 113.0 26.5 2 X
SMDJ75A SMDJ75CA PGR DGR 75.0 83.30 92.10 1 121.0 24.8 2 X
SMDJ78A SMDJ78CA PGT DGT 78.0 86.70 95.80 1 126.0 23.8 2 X
SMDJ85A SMDJ85CA PGV DGV 85.0 94.40 104.00 1 137.0 21.9 2 X
SMDJ90A SMDJ90CA PGX DGX 90.0 100.00 111.00 1 146.0 20.5 2 X
SMDJ100A SMDJ100CA PGZ DGZ 100.0 111.00 123.00 1 162.0 18.5 2 X
SMDJ110A SMDJ110CA PHE DHE 110.0 122.00 135.00 1 177.0 16.9 2 X
SMDJ120A SMDJ120CA PHG DHG 120.0 133.00 147.00 1 193.0 15.5 2 X
SMDJ130A SMDJ130CA PHK DHK 130.0 144.00 159.00 1 209.0 14.4 2 X
SMDJ150A SMDJ150CA PHM DHM 150.0 167.00 185.00 1 243.0 12.3 2 X
SMDJ160A SMDJ160CA PHP DHP 160.0 178.00 197.00 1 259.0 11.6 2 X
SMDJ170A SMDJ170CA PHR DHR 170.0 189.00 209.00 1 275.0 10.9 2 X
SMDJ 180 A SMDJ180CA PHT DHT 180.0 198.00 230.40 1 292.0 10.3 2 X
SMDJ220A SMDJ220CA PKE DKE 220.0 242.00 281.60 1 356.0 8.4 2 X
For parts without A , the V
BR
is + 10%, and V
C
is 5% higher than A parts.
For bidirectional type having V
R
of 10 volts and less, the I
R
limit is double.
