Hinged Plastic Covers
Clear Plastic Covers
powr-bloks
™
Distribution Block Selection Guide
amp
rating
per
pole
poles
Conne
Ctor
m
aterial
line ConneCtion
load ConneCtion
dra
wing
Catalog/
ordering
number
ConneCtor openings
per pole
lug tYpe wire range ConneCtor openings
per pole
lug tYpe wire range
760
1
AL
2
3/8" Hex
500mcm-#4
12
Slotted
#4 - #14
7
0LD55921Z
760
2
2
3/8" Hex
500mcm-#4
12
Slotted
#4 - #14
7
0LD55922Z
760
3
2
3/8" Hex
500mcm-#4
12
1/8" Hex
#4 - #14
7
LFD55923Z
380
1
AL
1
3/8" Hex
500mcm-#4
8
5/32" Hex
#2 - #14
7
0LD55941Z
380
2
1
3/8" Hex
500mcm-#4
8
5/32" Hex
#2 - #14
7
0LD55942Z
380
3
1
3/8" Hex
500mcm-#4
8
5/32" Hex
#2 - #14
7
0LD55943Z
760
1
CU
2
3/8" Hex
500mcm-#4
8
3/16" Hex
2⁄0 - #14
7
0LD59861Z
760
2
2
3/8" Hex
500mcm-#4
8
3/16" Hex
2⁄0 - #14
7
0LD59862Z
760
3
2
3/8" Hex
500mcm-#4
8
3/16" Hex
2⁄0 - #14
7
0LD59863Z
760
1
CU
2
3/8" Hex
500mcm-#4
12
Slotted
#2 - #14
7
0LD59921Z
760
2
2
3/8" Hex
500mcm-#4
12
Slotted
#2 - #14
7
0LD59922Z
760
3
2
3/8" Hex
500mcm-#4
12
Slotted
#2 - #14
7
0LD59923Z
175
1
AL
1
3/16" Hex
2⁄0 - #14
4
1/8" Hex
#4 - #14
4
0LD25701ZXDIN
175
2
1
3/16" Hex
2⁄0 - #14
4
1/8" Hex
#4 - #14
4
0LD25702ZXDIN
175
3
1
3/16" Hex
2⁄0 - #14
4
1/8" Hex
#4 - #14
4
0LD25703ZXDIN
175
Adder
1
–
2⁄0 - #14
4
–
#4 - #14
4
0LD2570AZXDIN
175
1
AL
1
–
2⁄0 - #14
6
–
#4 - #14
4
0LD25801ZXDIN
175
2
1
5/16" Hex
2⁄0 - #14
6
Slotted
#4 - #14
4
0LD25802ZXDIN
175
3
1
5/16" Hex
2⁄0 - #14
6
Slotted
#4 - #14
4
0LD25803ZXDIN
175
Adder
1
–
2⁄0 - #14
6
–
#4 - #14
4
0LD2580AZXDIN
175
1
CU
1
3/16" Hex
2⁄0 - #14
4
Slotted
#4 - #14
4
0LD29701ZXDIN
175
2
1
3/16" Hex
2⁄0 - #14
4
Slotted
#4 - #14
4
0LD29702ZXDIN
175
3
1
3/16" Hex
2⁄0 - #14
4
Slotted
#4 - #14
4
0LD29703ZXDIN
175
Adder
1
–
2⁄0 - #14
4
–
#4 - #14
4
0LD2970AZXDIN
Note: AL = Aluminum / CU = Copper
