TVS Diode Arrays
(SPA
®
Diodes)
Low Capacitance ESD Protection - SP3002 Series
Embossed Carrier Tape & Reel Specification — SOT23-6
Embossed Carrier Tape & Reel Specification — μDFN-6 (1.6x1.6x0.5mm)
8mm TAPE AND REEL
GENERAL INFORMATION
1. 3000 PIECES PER REEL.
2. ORDER IN MULTIPLES OF FULL REELS ONLY.
3. MEETS EIA-481 REVISION "A" SPECIFICATIONS.
2.0mm
4.0mm
CL
1.75mm
1.5mm
DIA. HOLE
8mm
4.0mm
8.4mm
180mm
14.4mm
13mm
60mm
ACCESS HOLE
COVER TAPE
USER DIRECTION OF FEED
PIN 1
SOT-23 (8mm POCKET PITCH)
K0
A0
B0
P2
D1
P0
t
F
E
W
D
Symbol
Millimetres
Inches
Min
Max
Min
Max
E
1.65
1.85
0.06
0.07
F
3.45
3.55
0.14
0.14
D1
1.00
1.25
0.04
0.05
D
1.50 MIN
0.06 MIN
P0
3.90
4.10
0.15
0.16
10P0
40.0± 0.20
1.57±0.01
W
7.90
8.30
0.31
0.33
P2
1.95
2.05
0.08
0.08
A0
1.78
1.88
0.07
0.07
B0
1.78
1.88
0.07
0.07
K0
0.84
0.94
0.03
0.04
t
0.25 TYP
0.01 TYP
Embossed Carrier Tape & Reel Specification — SC70-6
Symbol
Millimetres
Inches
Min
Max
Min
Max
E
1.65
1.85
0.064
0.073
F
3.45
3.55
0.135
0.139
P2
1.95
2.05
0.077
0.081
D
1.40
1.60
0.055
0.063
D1
1.00
1.25
0.039
0.049
P0
3.90
4.10
0.154
0.161
10P0
40.0± 0.20
1.574±0.008
W
7.70
8.10
0.303
0.318
P
3.90
4.10
0.153
0.161
A0
2.14
2.34
0.084
0.092
B0
2.24
2.44
0.088
0.096
K0
1.12
1.32
0.044
0.052
t
0.27 Max
0.010 Max
