Axial Lead & Cartridge Fuses

3AG > Time Lag > 313/315 Series

Electrical Characteristic Specifications by Item

Amp

Code

Ampere

Rating

(A)

Voltage

Rating

(V)

Interrupting

Rating

Nominal

Cold

Resistance

(Ohms)

Nominal

melting

I

2

t (A

2

sec)

Agency Approvals

PS

E

.010

0.01

250

35A@250Vac

10KA@125Vac

4300.0000

0.000121

x

x

x

.031

0.031

250

430.0000

0.00303

x

x

x

.040

0.04

250

300.0000

0.00630

x

x

x

.062

0.062

250

120.0000

0.0210

x

x

x

.100

0.1

250

43.0000

0.0850

x

x

x

.125

0.125

250

30.0000

0.152

x

x

x

.150

0.15

250

20.0000

0.270

x

x

x

.175

0.175

250

8.6700

0.177

x

x

x

.187

0.187

250

8.0100

0.230

x

x

x

.200

0.2

250

6.5900

0.270

x

x

x

.250

0.25

250

4.2700

0.385

x

x

x

.300

0.3

250

3.1350

0.730

x

x

x

.375

0.375

250

2.0950

1.23

x

x

x

.400

0.4

250

1.8750

1.35

x

x

x

.500*

0.5

250

1.2600

2.55

x

x

x

.600

0.6

250

0.9120

4.00

x

x

x

.700

0.7

250

0.7000

5.90

x

x

x

.750

0.75

250

0.6215

7.16

x

x

x

.800

0.8

250

0.5540

8.00

x

x

x

001.*

1

250

0.3750

14.0

x

x

x

x

01.2

1.2

250

100A@250Vac

10KA@125Vac

0.2780

21.5

x

x

x

x

1.25

1.25

250

0.2600

24.0

x

x

x

x

01.5*

1.5

250

0.1910

38.0

x

x

x

x

01.6

1.6

250

0.1710

49.6

x

x

x

x

01.8

1.8

250

0.1410

58.0

x

x

x

x

002.*

2

250

0.1169

77.0

x

x

x

x

2.25

2.25

250

0.0968

121

x

x

x

x

x

02.5

2.5

250

0.0811

130

x

x

x

x

x

02.8

2.8

250

0.0675

170

x

x

x

x

x

003.*

3

250

0.0593

200

x

x

x

x

x

03.2

3.2

250

0.0529

209

x

x

x

x

x

004.*

4

250

200@250Vac

10KA@125Vac

0.0311

76.1

x

x

x

x

x

005.*

5

250

0.0214

140

x

x

x

x

x

6.25*

6.25

250

0.0154

242

x

x

x

x

x

06.3

6.3

250

0.0154

242

x

x

x

x

x

007.*

7

250

0.0128

347

x

x

x

x

x

008.*

8

250

0.0111

445

x

x

x

x

x

010.**

10

250

300A@32Vac

0.0083

760

x

x

x

x

010.*

10

32

0.0083

760

x

012.

12

32

0.0065

1200

x

015.**

15

125

0.0050

1870

x

x

x

x

015.

15

32

0.0050

1870

x

020.

20

32

0.0022

9560

x

025.

25

32

0.0017

16500

x

030.

30

32

0.0012

26900

x

* For 313series, these ratings available with an indicating option. Add the “ID” designation to the series number. i.e. 313.500ID.

** These 2 ratings are designed for special voltage requirement. For 10A, it is available as 250Vac rated and the part number is 0313010.

MX250P; for 15A, it is available as 125Vac rated and the part number is 0315015.MX125P.
