SIDACtor ® Protection Thyristors
357
Revised: March 28, 2012
© 2012 Littelfuse, Inc.
Specifications are subject to change without notice.
Please refer to www.littelfuse.com for current information.
Teccor ® brand SIDACtor ® DSL Protection Devices
-8
-40 -20 0 20 40 60 80 100 120 140 160
-6
-4
0
2
4
6
8
10
12
14
Junction Temperature (T
J
) – °C
Percent of
V
S
Change – % 25 °C
25°C
Case Temperature (T
C
) - ºC
2.0
1.8
1.6
1.4
1.2
1.0
0.8
0.6
0.4
-40 -20 0 20 40 60 80 100 120 140 160
R
atio of
I H
I H
(T
C
= 25ºC)
V
S
vs. Junction Temperature Holding Current vs. Case Temperature
I
H
I
T
I
S
I
DRM
V
DRM
V
T
+V -V
+I
-I
V
S
V-I Characteristics Capacitance vs. Bias Voltage*
0
2
4
6
8
10
12
14
6 7 4 0 1 2 3 5 8
Off-State Voltage (V)
Capacitance (pF)
Package Symbol Parameter Value Unit
T
J
Operating Junction Temperature Range -40 to +150 °C
T
STG
Storage Temperature Range -40 to +150 °C
R
0JA
Thermal Resistance: Junction to Ambient 120 °C/W
Thermal Considerations
1
2
3
5
4
3
