Transient voltage suppression diodes, Sma6j xx a, Surface mount – 600w > sma6j series – Littelfuse SMA6J Series User Manual
Page 5
Transient Voltage Suppression Diodes
© 2014 Littelfuse, Inc.
Specifications are subject to change without notice.
Revised: 01/20/14
Surface Mount – 600W > SMA6J series
Part Numbering System
Part Marking System
SMA6J xx A
SERIES
5%
V
BR
VOLTAGE TOLERANCE
V
R
VOLTAGE
F
XX
YMXXX
Marking Code
Trace Code Marking
Y:Year Code
M: Month Code
XXX: Lot Code
Littelfuse Logo
Cathode Band
(for uni-directional products only)
Packaging
Part number
Component
Package
Quantity
Packaging
Option
Packaging
Specification
SMA6JxxX
DO-214AC
5000
Tape & Reel - 12mm tape/13” reel
EIA RS-481
Cathode
Tape and Reel Specification
0.47
(12.0)
0.157
(4.0)
0.157
(4.0)
0.49
(12.5)
0.80 (20.2)
Arbor Hole Dia.
13.0 (330)
Dimensions are in inches
(and millimeters).
Direction of Feed
0.059 DIA
(1.5)
Cover tape
