Littelfuse SL0902A Series - Manual (Page 3)

©2012 Littelfuse, Inc.
Gas Discharge Tube (GDT) Products
9
Revised: September 17, 2012
Specifications are subject to change without notice.
Please refer to www.littelfuse.com for current information.
Customer should verify actual device performance in their specific applications.
CG5 and SL0902A Series
CG5 and SL0902A Series
Device Dimensions
5.0 ± 0.2
0.80 DIA. TYP.
[0.024]
62 ± 2
[0.197 ± 0.008]
[2.441 ± 0.079]
PROFILE VIEW TOP VIEW
5.0 ± 0.2
[0.197 ± 0.008]
Outline 502 - CG5xxxLTR (also CG5350L-03TR, CG5600L-02)
5.0 ± 0.2
[0.197 ± 0.008]
PROFILE VIEW TOP VIEW
5.0 ± 0.15
[0.197 ± 0.006]
Outline 501 - CG5xxx
[0.209 ± 0.012]
5.30 ± 0.30
[0.197 ± 0.008]
5.00 ± 0.20
[0.016 ± 0.0012]
0.40 ± 0.03
0.004
2 Surfaces
[0.031]
0.80
[0.315 ± 0.012]
8.00 ± 0.30
[0.366 ± 0.012]
9.30 ± 0.30
[0.209 ± 0.012]
5.30 ± 0.30
5.00 ± 0.20
[0.197 ± 0.008]
40° ± 3°
8.00
[0.315]
9.80
[0.386]
5.50
[0.216]
1.80
[0.071]
PROFILE VIEW
SOLDER PAD LAYOUT
TOP VIEW
Outline 500 - CG5xxxLS
5.0 ± 0.2
0.80 DIA. TYP.
[0.031] 6.3 ± 0.2
[0.197 ± 0.008]
5.0 ± 0.2
[0.197 ± 0.008]
3.0 ± 0.3
[0.118 ± 0.008]
[2.480 ± 0.079]
PROFILE VIEW TOP VIEW
Outline 503 - CG5xxxL-02 (except CG5600L-02, see Outline 502)
5.0 ± 0.2
[0.197 ± 0.008]
0.5 ± 0.1
[0.02 ± 0.004 ]
6.6 ± 0.2
[0.260 ± 0.008]
3.8
[0.15]
5.4 ± 0.15
[0.212 ± 0.006]
4.50
[0.18]
5.10
[0.2]
PROFILE VIEW TOP VIEW
SOLDER PAD LAYOUT
0.70
[0.028]
5.4 ± 0.15
[0.212 ± 0.006]
Outline 505 - CG5xxxMS and SL0902AxxxSM
