Strike Application Information
Strike Application/Minimum Stile Using Standard Trim
Standard Optional
Single door Double door Single door Double door
Strike Stile Strike w/Mullion* Stile Strike Stile Strike w/Mullion* Stile
1409 3-13/16" (97mm) 299 x 5654 4-7/16" (113mm)
CX98 299 4-1/2" (114mm) 299 x 4954 4-7/8" (124mm) 1410 3-13-16" (97mm) 1408 x 5754 3-13/16" (97mm)
CX99 1606 4-1/16" (103mm) 1606 x 1654 4-7/16" (113mm)
CX98-F/CX99-F 299F 4-1/2" (114mm) 499F x 9954 4-7/8" (124mm) — — — —
Strike Stile Strike Stile Strike
CX9875 575-2
CX9975 575 4-3/4" (121mm) — — — — 576A-576B 4-3/4" (121mm)
CX9875-F 575-2
CX9975-F 575 4-3/4" (121mm) — — — — 576A-576B 4-3/4" (121mm)
Strike Application Stile Strike Application Stile
CX9847 338 (Top) Single door 3-11/16" (94mm) 283 (Top) Single door 3-11/16" (94mm)
CX9947 385A (Bottom) Two Vertical 304L (Bottom) Two Vertical
CX9847WDC Rod Devices 3-11/16" (94mm) Rod Devices 3-11/16" (94mm)
CX9947WDC Vertical Rod Vertical Rod
w/Mortise w/Mortise
Lock Device 4-3/4" (121mm) Lock Device 4-3/4" (121mm)
CX9847-F 338 (Top) Two Vertical 4-1/4" (108mm) 304L (Bottom) Single door 4-1/4" (108mm)
CX9947-F 385A (Bottom) Rod Devices Rod Devices
CX9847WDC-F
CX9947WDC-F
*Mullion information — refer to General and Auxiliary section.
Device
Type
