15

Applications and Wiring

120 VAC

3 x 14 ga.

To Fire Alarm

2 x 18 ga.

Junction

Box

EPT-10

EPT-10

PS871/873
Power Supply

PS871/873
Power Supply

Cable

Cable

2 x 12 ga.
3 x 18 ga.

2 x 12 ga.
3 x 18 ga.

Gnd

Gnd

+24

+24

SC

FA

DPS

EI

CM+

CM–

NO

C

Chexit 1

Red

Black

White

Yellow

Orange

Green

Gray

Violet

Blue

Brown

Gnd

+24

SC

FA

DPS

EI

CM+

CM–

NO

C

Chexit 2

Red

Black

White

Yellow

Orange

Green

Gray

Violet

Blue

Brown

2 x 12 ga.

Fire Alarm

120 VAC

3 x 14 ga.

To Fire Alarm

2 x 18 ga.

Junction

Box

EPT-10

EPT-10

PS871/873
Power
Supply

Cable

Cable

2 x 12 ga.
8 x 18 ga.

2 x 12 ga.
8 x 18 ga.

Gnd

Gnd

+24

+24

SC

FA

DPS

EI

CM+

CM–

NO

C

Chexit 1

Red

Black

White

Yellow

Orange

Green

Gray

Violet

Blue

Brown

Gnd

+24

SC

FA

DPS

EI

CM+

CM–

NO

C

Chexit 2

Red

Black

White

Yellow

Orange

Green

Gray

Violet

Blue

Brown

2 x 12 ga.

2 x 18 ga.

2 x 18 ga.

2 x 18
ga.

2 x 18 ga.
(input)

Fire Alarm

Card Reader

Horn

Horn

Card

Reader

(Inside or

Outside)

Magnetic

Switch

Magnetic

Switch

Door

Door

Position

Position

Basic Chexit Double Door application. When one Chexit is set into
alarm, the other will also go into alarm. In an emergency situation both
doors will disarm simultaneously.

Double Door Chexit with Options shows the proper wiring for double
door. The card reader will unlock both doors upon authorized access.
For proper operation the rearm times are set two seconds apart.

PS873

PS873
