Com-Tech 200/400/800/1600 Power Amplifiers

ILLUSTRATIONS

1.1

Com-Tech Amplifiers (120 VAC, 60 Hz Units) ........................... 6

2.1

Front Facilities ........................................................................... 8

2.2

Rear Facilities ............................................................................ 9

3.1

Mounting Dimensions .............................................................. 10

3.2

Top View of a Rack-Mounted Unit ........................................... 11

3.3

Extra Cooling with a Rack-Mounted Blower ............................ 12

3.4

Wiring for Dual 8/4 Ohm Mode ................................................ 13

3.5

Wiring for Dual 70 Volt Mode ................................................... 14

3.6

Wiring for Bridge-Mono 70 Volt Mode (140 Volt Output) ......... 15

3.7

Wiring for Parallel-Mono 70 Volt, Bridge-Mono 8/4 Ohm
and Parallel-Mono 8/4 Ohm Modes ......................................... 16

3.8

Unbalanced Input Wiring ........................................................ 17

3.9

Balanced Input Wiring ............................................................. 17

3.10 Subsonic Filter Capacitor Values ............................................ 17
3.11 Unbalanced RFI Filters ............................................................ 18
3.12 Balanced RFI Filters ................................................................ 18
3.13 Wire Size Nomograph ............................................................. 19
3.14 Inductive Load (Transformer) Network .................................... 20
3.15 Loudspeaker Fuse Nomograph .............................................. 20
4.1

ODEP, IOC and Signal Presence Indicator States .................. 23

4.2

Input Sensitivity Switch ............................................................ 25

5.1

Circuit Block Diagram ............................................................. 27

6.1

Com-Tech 200 Minimum Power Matrix ................................... 32

6.2

Com-Tech 400 Minimum Power Matrix ................................... 33

6.3

Com-Tech 800 Minimum Power Matrix ................................... 34

6.4

Com-Tech 1600 Minimum Power Matrix ................................. 35

6.5

Com-Tech 200 Maximum Power Matrix .................................. 36

6.6

Com-Tech 400 Maximum Power Matrix .................................. 37

6.7

Com-Tech 800 Maximum Power Matrix .................................. 38

6.8

Com-Tech 1600 Maximum Power Matrix ................................ 39

6.9

Typical Frequency Response ................................................. 40

6.10 Typical Damping Factor .......................................................... 40
6.11 Typical Output Impedance ...................................................... 40
6.12 Typical Phase Response ......................................................... 41
6.13 Typical Crosstalk ..................................................................... 41
7.1

Com-Tech 200 Power Draw, Current Draw and
Thermal Dissipation at Various Duty Cycles ........................... 42

7.2

Com-Tech 400 Power Draw, Current Draw and
Thermal Dissipation at Various Duty Cycles ........................... 43

7.3

Com-Tech 800 Power Draw, Current Draw and
Thermal Dissipation at Various Duty Cycles ........................... 43

7.4

Com-Tech 1600 Power Draw, Current Draw and
Thermal Dissipation at Various Duty Cycles ........................... 43

8.1

Installing a

P.I.P. Module ......................................................... 44

8.2

Cooling Fan Option ................................................................. 46

8.3

Cooling Fan Assembly ............................................................ 46
