14

4.4. Output Segment Function Configure menu

When main menu Type 2 and press Enter. The menu displays the Output Segment Function

Configure and current setting status as below, in this menu type 0, the menu will return to

Figure12. Main menu

-----------------------------------------------------------------------------

Output Segment Function Configure

-----------------------------------------------------------------------------

1. Segment 1 function, Current Setting(Utility Failure)

2. Segment 2 function, Current Setting(Battery Low)

3. Segment 3 function, Current Setting(General Alarm)

4. Segment 4 function, Current Setting(Bypass Status)

5. Segment 5 function, Current Setting(Summary Alarm)

0. Exit
-----------------------------------------------------------------------------

Please Enter Number:

Figure16. Output Segment select menu

Default of each Segment

1.

Segment 1 function default is Utility Failure

2.

Segment 2 function default is Battery Low

3.

Segment 3 function default is General Alarm

4.

Segment 4 function default is Bypass Status

5.

Segment 5 function default is Summary Alarm

When Figure16. Output Segment select menu Type 1~5 and press Enter. The menu displays

output function select menu as below, in this menu select any list number, the menu will return to

Figure16. Output Segment select menu

-----------------------------------------------------------------------------

Segment 1 Function

-----------------------------------------------------------------------------

1. Utility Failure

2. Battery Low

3. General Alarm

4. Bypass Status

5. Summary Alarm

6. Battery Testing

7. Shutdown Processing

8. Over Load Warning

0. Exit

-----------------------------------------------------------------------------

Please Enter Number:

Figure17. Output function select menu
