Packing List
When you unpack this product package, you will find the items listed below. Please inspect the contents, and report any apparent damage
or missing items immediately to our authorized reseller.
 The Hardened Ethernet Extender
 CD with user’s Manual
 Quick Start Guide
 AC to DC Power Adaptor and Power Cable (optional)
One-Channel Hardened Ethernet Extender
Ports
The Hardened Ethernet Extender provides TX ports and one Ethernet Extender port. For the TX ports, it uses RJ-45 connector and auto
senses the speed of 10/100Mbps.For the Ethernet Extender port, it uses RJ-11 and Terminal Block connectors and auto senses the speed
of 1/3/5/10/15/20/25/30/40/50Mbps.
Ethernet Extender Mode Settings
Ethernet Extender mode settings are made very simple by means of a DIP (Dual Inline Package) switch on the top panel of the Hardened
Ethernet Extender.
DIP switch
There is one pin on the DIP switch for Ethernet Extender mode settings. Refer to the table below for more details.
Loc Rmt
The device operates in local mode The device operates in remote mode
Front Panel & LEDs
LED Indicators
The LED indicators give you instant feedback on status of the Hardened Ethernet Extender:
LEDs State Indication
Power1
Power2
Power3
Steady Power on
Off Power off
Ethernet
PoE
Steady Powered Device (PD) is connected
Off Powered Device (PD) is disconnected
Link/ACT
(Green)
Steady Valid network connection established
Flashing
Transmitting or receiving data
ACT stands for ACTIVITY
Off
Neither valid network connection established
nor transmitting/receiving data
Speed
(Yellow)
Steady Valid port connection at 100Mbps
Off Valid port connection at 10Mbps
Ethernet Extender
Remote Steady The device operates in remote mode
Local Steady The device operates in local mode
Error Steady Error occurred
Link Steady A valid connection established
Ethernet Extender
Speed Distance
1Mbps 1,900 M (6,232 ft.)
3Mbps 1,800 M (5,904 ft.)
5Mbps 1,600 M (5,249 ft.)
10Mbps 1,400 M (4,593 ft.)
15Mbps 1,200 M (3,936 ft.)
20Mbps 1,000 M (3,280 ft.)
25Mbps 800 M (2,624 ft.)
30Mbps 700 M (2,296 ft.)
40Mbps 600 M (1,968 ft.)
50Mbps 300 M (984 ft.)
