Specifications
Applicable Standards IEEE802.3 10Base-T, IEEE802.3u 100Base-TX,
Ethernet over VDSL, IEEE802.3at
Fixed Ports 10/100Mbps Ethernet ports with RJ-45 connectors
1 x Ethernet Extender port with RJ-11 and Terminal Block connectors
Speed
10Base-T
100Base-TX
Ethernet Extender
10/20Mbps for half/full-duplex
100/200Mbps for half/full-duplex
1, 3, 5, 10, 15, 20, 25, 30, 40, 50Mbps
Switching Method Store-and-Forward
Forwarding rate 14,880/148,810pps for 10/100Mbps
Cable
10Base-T
100Base-TX
Ethernet Extender 4-pair UTP/STP Cat. 3, 4, 5 up to 100m
4-pair UTP/STP Cat. 5 up to 100m
Telephone wires
LED Indicators Per Unit (3 LEDs)- Power1, Power2, Power3
Per Port-
RJ-45 (2 or 3 LEDs): Link/ACT (Green), Speed (Yellow), PoE (Only available for Hardened IEEE802.3at
PoE PSE Ethernet Extender version)
RJ-11, Terminal Block (14 LEDs): Remote, Local, Error, Link, 1Mbps, 3Mbps, 5Mbps, 10Mbps, 15Mbps,
20Mbps, 25Mbps, 30Mbps, 40Mbps, 50Mbps
Dimensions 50mm (W) × 110mm (D) x 135mm (H)
(1.97” (W) x 4.33” (D) x 5.31” (H))
Weight 0.8Kg (1.76lbs.)
Power
Terminal Block: 24-48VDC
DC Jack: 48VDC, External AC/DC required
Operating Voltage
Max. Current Consumption
Power Consumption
4 x 10/100Base-TX (2 x IEEE802.3at PoE PSE) 2.88A @ 24VDC, 1.44A @ 48VDC, 69.12W Max.
2 x IEEE802.3at PoE PSE 2.88A @ 24VDC, 1.44A @ 48VDC, 69.12W Max.
1 x IEEE802.3at PoE PSE 1.6A @ 24VDC, 0.8A @ 48VDC, 38.4W Max.
4 x 10/100Base-TX 0.36A @ 24VDC, 0.18A @ 48VDC, 8.64W Max.
Operating Temperature -40°C ~ 75°C (-40℉ ~ 167℉)
Tested for functional operation @
-40°C ~ 85°C (-40℉ ~ 185℉)
UL508 Industrial Control Equipment certified Maximum Surrounding Air Temperature @ 75℃ (167℉)
Storage Temperature -40°C ~ 85°C (-40°F ~ 185°F)
Humidity 5 ~ 95%, non-condensing
Safety UL508
EMI FCC Part 15, Class A
EN61000-6-4: EN55022, EN61000-3-2, EN61000-3-3
EMS EN61000-6-2:
EN61000-4-2 (ESD Standard)
EN61000-4-3 (Radiated RFI Standards)
EN61000-4-4 (Burst Standards)
EN61000-4-5 (Surge Standards)
EN61000-4-6 (Induced RFI Standards)
EN61000-4-8 (Magnetic Field Standards)
Environmental Test
Compliance
IEC60068-2-6 Fc (Vibration Resistance)
IEC60068-2-27 Ea (Shock)
IEC60068-2-32 Ed (Free Fall)
NEMA TS1/2 Environmental requirements for traffic control equipment
