Hardware Description
5 Manual Documentation Number EIR405-T – 0912m
www.bb-elec.com
www.bb-europe.com
LED Indicators
LED Status Meaning
PWR1
Green Power 1 is active
Off No power at input 1
PWR2
Green Power 2 is active
Off No power at input 2
Fault
Red
Power 1 or Power 2 is
inactive
Off
Power 1 and 2 are both
functional, or no power is
applied
P9, P10
(10/100/1000T,Upper LED)
Green Connected to network
Blinks Networking is active
Off Not connected to network
P9, P10
(10/100/1000T, Lower LED)
Green
The port is operating at
speed of 1000M
Off
The port is disconnected or
operating at speed of
10/100M
Link/Active
(P9, P10 SFP)
Green SFP port is linking
Blinks
Data is transmitting or
receiving
Off Not connected to network
P1 to P8
On Connected to network
