Hardware Description
6 Manual Documentation Number EIR405-T – 0912m
www.bb-elec.com
www.bb-europe.com
(Green LED)
Blinks
Networking is active
Off Not connected to network
P1 to P8
(Yellow LED)
On Full duplex operation
Blinks Collision of packets occurs
Half duplex operation or not
Off
connected to network
Ports
• RJ-45 ports
• RJ-45 ports: Eight RJ-45 ports auto-sense for 10, 100 Mbps while two ports auto-sense
for 10, 100 or 1000 Mbps device connections. The auto MDI/MDIX feature allows
connections to switches, workstation and other equipment without changing straight
through or crossover cabling. The charts below show the cable pin assignments for
straight through and crossover cables.
• RJ-45 Pin Assignments
Pin Number Assignment
1 Tx+
2 Tx-
3 Rx+
6 Rx-
Note
“+” and “-” signs represent the polarity of each wire pair.
All copper ports on the EIR410-2SFP-T support automatic MDI/MDI-X operation, you can
use straight-through cables (See Figure below) for all network connections to PCs or servers,
