DUALCON-3 USERS GUIDE
4.1.6 RTD Input
Select the range from the table below and set Switch S1 to the required values.
Range in °C
1 2 3 4 5 6 7 8 9 10 11 12
0 to 100 0 0 0 0 0 0 1 0 0
0 to 200 0 0 0 1
0 to 400 0 0 1 0
0 to 800 0 0 1 1
-50 to 50 0 1 0 0
-50 to 150 0 1 0 1
-50 to 250 0 1 1 0
-50 to 350 0 1 1 1
-100 to 50 1 0 0 0
-100 to 100 1 0 0 1
-100 to 200 1 0 1 0
-100 to 400 1 0 1 1
-200 to 200 1 1 0 0
-200 to 400 1 1 0 1
-200 to 600 1 1 1 0
-200 to 800 1 1 1 1 0 0 1 0 0
RTD linearisation ON 0 PT100 0
RTD linearisation off 1 PT1000 1
RTD 2 or 4 wire 0
RTD 3 wire 1
Switch S1
And then select the required setting from the table below for switch S2
RTD
1 2 3 4 5 6 7 8 9 10 11 12
2 Wire RTD 0 1 0 0 1 0 0 1 0 0 0 1
3 Wire RTD 0 1 0 0 0 0 0 0 1 0 0 1
4 Wire RTD 0 1 0 0 0 0 0 1 0 1 0 0
Switch S2
Please note that PC Software is available to provide information on
switch settings for your input and output requirements.
! WARNING !
DO NOT OPEN UNIT OR ADJUST SWITCHES WITH
POWER SUPPLY, INPUT OR OUTPUT CONNECTED
!
