Transmit Data Source iVIEW 2
S2-9: ON S2-10: ON Standard Data iVIEW 2 default
S2-9: OFF S2-10: ON Transmit Pseudorandom Bit Sequence (PRBS) iVIEW 2
S2-9: ON S2-10: OFF Transmit Alternating Ones and Zeros iVIEW 2
S2-9: OFF S2-10: OFF Transmit Unframed All Ones iVIEW 2
Switch Settings for Switch S3
S W
I
T C H
S 3
Jitter Attenuator Select
S3-1: ON Place Jitter Attenuator on RCV Side
S3-1: OFF Place Jitter Attenuator on XMT Side default
Remote Unit
S3-2: ON Remote Unit Enabled (only at the REMOTE end)
S3-2: OFF Remote Unit Disabled (only at the LOCAL end) default
Loopback Selection iVIEW 2
S3-3: ON S3-4: ON None iVIEW 2 default
S3-3: OFF S3-4: ON Local Loopback iVIEW 2
S3-3: ON S3-4: OFF Analog Loopback iVIEW 2
S3-3: OFF S3-4: OFF Remote Loopback iVIEW 2
Monitor/Boost Mode
S3-5: ON S3-6: ON Normal Operation (No Boost) default
S3-5: OFF S3-6 ON 20 dB
S3-5: ON S3-6 OFF 26 dB
S3-5: OFF S3-6 OFF 32 dB
NRZ Selection iVIEW 2
S3-7: ON Disable NRZ (Required for Passive Mode) iVIEW 2 default
S3-7: OFF Enable NRZ (Line Terminating Mode) iVIEW 2
Fiber Type
S3-8: Factory Configured DO NOT CHANGE
S3-9: Factory Configured DO NOT CHANGE
S3-10: Factory Configured DO NOT CHANGE
Description of DIP Switch-Selectable Options
The iMcV-T1/E1/J1 Repeater module includes DIP Switches for hardware settings
for the optional features. Some of these switch options are overridden by the
