2
Configuration Instructions
The iMcV-T1/E1/J1 Repeater module is factory-configured to use the following
default features:
T1/E1 Mode T1
Receive Equalizer Gain Limit (EGL) -30 dB (Limited Long Haul)
Line Encoding AMI (Passive Mode)
Transmit LIU Waveshape (Build-
out) DSX-1 (0 to 133 ft) 0 dB CSU
Receive LIU Termination Receive Side 100 ohms Enabled
Transmit Data Source Standard Data
Jitter Attenuator Select Place Jitter Attenuator on TX Side
Remote Unit Remote Unit Disabled
Loopback Selection No Loopback
Monitor/Boost Mode No Boost
NRZ Selection Disable NRZ (Passive Mode)
The iView 2 management software can be used to change some of the
iMcV-T1/E1/J1 Repeater features after installing the modules in the chassis. Refer
to the iView
2 online help for more information.
Passive Mode
It is recommended that the default Passive mode configuration is used for most
typical applications. Passive mode allows the fiber segment to pass data
unchanged between the T1/E1 segments independent of the actual line coding
(AMI, B8ZS, or HDB3). All errors and fault conditions from one T1/E1 end will
pass through the fiber to the other end as if there were one long T1/E1
connection.
Requirements
Before installing the iMcV-T1/E1/J1 Repeater modules, perform the following:
 Make sure the modules are correct for the fiber type and distance
requirements.
 Make sure that T1 UTP lines DO NOT use simplex power (no wet lines).
 Before installing the iMcV-T1/E1/J1 Repeater modules, verify the DIP
Switches are configured for the feature wanted.
