7
SNMP configuration of a managed chassis (refer to the DIP Switch Table section
for a list of the iView
2 managed switches).
The following section contains a brief description of the available options.
T1/E1/J1 Mode
This option allows the user to select the data rate standard that the module will
use when converting: T1/J1 (default) or E1. The default is OFF, T1/J1 mode
selected.
Receive Equalizer Gain Limit (EGL)
The copper line receiver sensitivity can be adjusted with this setting. This can be
used to extend the service distance beyond the normal line length.
T1 Lines Can extend the effective received signal level from -30dB to -36dB
E1 Lines Can extend the effective received signal level from -12dB to -43dB
The addition of this gain can extend the service distance of these lines to 2K feet.
