12
By default this feature is set to Standard Data.
This feature can be controlled by SNMP-Management software (iView
2
) when the
HOST IE-iMcV-T1/E1/J1-LineTerm, TP/SFP module is installed in a managed
chassis.
T1, E1 and J1 Selection
This switch selects the data rate to use on the copper line. The data rate
selections available include the following:
T1/J1 (1.544 Mbps +/- 32 ppm)
E1 (2.048 Mbps +/- 32 ppm)
By default this feature is set to T1.
This feature can be selected only by setting the DIP Switches manually.
Remote Management
A DIP Switch enables or disables the Remote Management mode. By default this
feature is Disabled. Remote Management must be enabled on the REMOTE
module. This allows all SNMP-configurable features for the REMOTE modules to
be configured from the HOST module.
An IE-iMcV-T1/E1/J1-LineTerm w/SFP Module with Configuration Control,
configured as a Host, allows an SNMP Management Module in a managed
chassis to manage the Remote. All settings are enabled and enforced through
the SNMP. The Host keeps a copy of the Remote’s configuration settings.
When the Host unit is in a managed chassis, the Host configures the Remote. This
ensures that the Remote’s configuration will not revert to its DIP Switch settings
and potentially disrupt traffic. However, if the customer changes the DIP Switch
settings on the Remote, the new configuration of the Remote will be saved by the
host.
When SNMP management is installed at the Host, the following functions at the
Remote are controlled from the Host unit:
Loopback
Line Code
Transmit Data Source
Fault Loopback
