232SPS2-0812 Manual Appendix A: Parallel Port Connections A-2
B&B Electronics -- PO Box 1040 -- Ottawa, IL 61350
PH (815) 433-5100 -- FAX (815) 433-5104
Table A-2
Serial to Parallel Mode
DB-25
Pin #
Signal Name 232SPS2
Direction
1 Strobe Output
2 Data bit #0 Output
3 Data bit #1 Output
4 Data bit #2 Output
5 Data bit #3 Output
6 Data bit #4 Output
7 Data bit #5 Output
8 Data bit #6 Output
9 Data bit #7 Output
10 Acknowledge Input
11 Busy Input
12 PE Input (NU)
13 SLCT Input (NU)
14 Auto Feed
“1” Output
15 Error Input (NU)
16 INIT
“1” Output
17 SLCT IN
“1” Output
18-25 GND
