Appendix A: Parallel Port Connections

A-1

B&B Electronics -- PO Box 1040 -- Ottawa, IL 61350

PH (815) 433-5100 -- FAX (815) 433-5104

APPENDIX A: PARALLEL PORT CONNECTIONS

The parallel port connections for the parallel to serial and serial

to parallel mode are shown in Table A-1, and Table A-2, respectively.
The connections required are the same for both modes of
handshaking. The error lines on the parallel port are forced to the "no
error" states. If the printer is off-line, out of paper, etc., the 232SPS2
will force the busy line (Pin #11) on the parallel port high (logic "1")
when in parallel to serial mode. If a error occurs in serial to parallel
mode, the XOFF character will be sent or DTR will be lowered
depending on type of flow control used. (NU - Indicates a signal is
not used or is not “passed through”)


Table A-1

Parallel to Serial Mode

DB-25

Pin #

Signal Name

232SPS2

Direction

1

Strobe

Input

2

Data bit #0

Input

3

Data bit #1

Input

4

Data bit #2

Input

5

Data bit #3

Input

6

Data bit #4

Input

7

Data bit #5

Input

8

Data bit #6

Input

9

Data bit #7

Input

10

Acknowledge

Output

11

Busy

Output

12

PE

"0" Output

13

SLCT

“1” Output

14

Auto Feed

Input (NU)

15

Error

"1" Output

16

INIT

Input (NU)

17

SLCT IN

Input (NU)

18-25

GND
