MAX157/MAX159
+2.7V, Low-Power, 2-Channel,
108ksps, Serial 10-Bit ADCs in 8-Pin µMAX
6 _______________________________________________________________________________________
Typical Operating Characteristics (continued)
(V DD = +3.0V, V REF = 2.5V, 0.1µF capacitor at REF, f SCLK = 2.17MHz, 16 clocks/conversion cycle (108ksps); CH- = GND for
MAX159; T A = +25°C, unless otherwise noted.)
-0.2
0.1
-0.1
0
0.2
2.5 3.0 3.5 4.0 5.0 4.5 5.5
GAIN ERROR
vs. SUPPLY VOLTAGE
MAX157/159 toc08
V DD (V)
GAIN ERROR (LSB)
-0.2
0.1
0
-0.1
0.2
-60 15 -35 -10 40 65 90 115 140
GAIN ERROR
vs. TEMPERATURE
MAX157/159 toc09
TEMPERATURE (°C)
GAIN ERROR (LSB)
0
0.15
0.10
0.05
0.20
-60 40 -35 -10 15 90 115 65 140
INTEGRAL NONLINEARITY
vs. TEMPERATURE
MAX157/159 toc12
TEMPERATURE (°C)
INL (LSB)
-0.03
-0.02
0
-0.01
0.02
0.01
0.03
0 500 250 750 1000
INTEGRAL NONLINEARITY
vs. OUTPUT CODE
MAX157/8 toc10
OUTPUT CODE
INL (LSB)
0
0.15
0.10
0.05
0.20
2.5 4.0 3.0 3.5 4.5 5.0 5.5
INTEGRAL NONLINEARITY
vs. SUPPLY VOLTAGE
MAX157/159 toc11
V DD (V)
INL (LSB)
