MAX1710/MAX1711/MAX1712

High-Speed, Digitally Adjusted
Step-Down Controllers for Notebook CPUs

2

_______________________________________________________________________________________

ABSOLUTE MAXIMUM RATINGS

Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.

V+ to GND ..............................................................-0.3V to +30V
V

CC

, V

DD

to GND .....................................................-0.3V to +6V

PGND to GND.....................................................................±0.3V
SHDN, PGOOD to GND ...........................................-0.3V to +6V
OVP, ILIM, FB, FBS, CC, REF, D0–D4,

GNDS, TON to GND ..............................-0.3V to (V

CC

+ 0.3V)

SKIP to GND (Note 1).................................-0.3V to (V

CC

+ 0.3V)

DL to PGND................................................-0.3V to (V

DD

+ 0.3V)

BST to GND ............................................................-0.3V to +36V

DH to LX .....................................................-0.3V to (BST + 0.3V)
LX to BST..................................................................-6V to +0.3V
REF Short Circuit to GND ...........................................Continuous
Continuous Power Dissipation (T

A

= +70°C)

24-Pin QSOP (derate 9.5mW/°C above +70°C)..........762mW

Operating Temperature Range ...........................-40°C to +85°C
Junction Temperature ......................................................+150°C
Storage Temperature Range .............................-65°C to +165°C
Lead Temperature (soldering, 10s) .................................+300°C

V

BATT

= 4.5V to 28V, includes

load regulation error

SHDN = 0, measured at V+ = 28V, V

CC

= V

DD

= 0 or 5V

SHDN = 0

V

CC,

V

DD

SHDN = 0

Battery voltage, V+

Measured at V+

Measured at V

DD

, FB forced above the regulation point

Measured at V

CC

, FB forced above the regulation point

Rising edge of SHDN to full I

LIM

(Note 2)

V

BATT

= 24V,

FB = 2V
(Note 2)

FB (MAX1710 only) or FBS

FB - FBS or GNDS - GND = 0 to 25mV

V

CC

= 4.5V to 5.5V, V

BATT

= 4.5V to 28V

CONDITIONS

µA

<1

5

Shutdown Battery Supply
Current

µA

<1

5

Shutdown Supply Current (V

DD

)

µA

<1

5

Shutdown Supply Current (V

CC

)

µA

25

40

Quiescent Battery Supply Current

µA

<1

5

Quiescent Supply Current (V

DD

)

µA

600

950

Quiescent Supply Current (V

CC

)

ns

400

500

Minimum Off-Time

380

425

470

260

290

320

175

200

225

%

-1

1

DC Output Voltage Accuracy

TON = REF (400kHz)

4.5

5.5

V

2

28

Input Voltage Range

TON = GND (550kHz)

ns

140

160

180

On-Time

ms

1.7

Soft-Start Ramp Time

µA

-1

1

GNDS Input Bias Current

µA

-0.2

0.2

FB Input Bias Current

TON = open (300kHz)

mV

3

Remote-Sense Voltage Error

mV

5

Line Regulation Error

UNIT

MIN

TYP

MAX

PARAMETER

Falling edge, hysteresis = 40mV

REF in regulation

I

REF

= 0 to 50µA

V

CC

= 4.5V to 5.5V, no external REF load

V

1.6

REF Fault Lockout Voltage

µA

10

REF Sink Current

V

0.01

Reference Load Regulation

V

1.98

2

2.02

Reference Voltage

TON = V

CC

(200kHz)

Note 1: SKIP may be forced below -0.3V, temporarily exceeding the absolute maximum rating, for the purpose of debugging proto-

type breadboards using the no-fault test mode. Limit the current drawn to -5mA maximum.

ELECTRICAL CHARACTERISTICS

(Circuit of Figure 1, V

BATT

= 15V, V

CC

= V

DD

= 5V, SKIP = GND, T

A

= 0°C to +85°C, unless otherwise noted.)

k

130

180

240

FB Input Resistance
(MAX1711/MAX1712)

DAC codes from 1.3V to 2V

-1.2

1.2

I

LOAD

= 0 to 7A

mV

9

Load Regulation Error

DAC codes from 0.925V
to 1.275V
