MAX1207
65Msps, 12-Bit ADC
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
V
DD
to GND ...........................................................-0.3V to +3.6V
OV
DD
to GND........-0.3V to the lower of (V
DD
+ 0.3V) and +3.6V
INP, INN to GND ...-0.3V to the lower of (V
DD
+ 0.3V) and +3.6V
REFIN, REFOUT, REFP, REFN,
COM to GND.....-0.3V to the lower of (V
DD
+ 0.3V) and +3.6V
CLKP, CLKN, CLKTYP, G/
T, DCE,
PD to GND ........-0.3V to the lower of (V
DD
+ 0.3V) and +3.6V
D11–D0, I. C., DAV, DOR to GND ...........-0.3V to (OV
DD
+ 0.3V)
Continuous Power Dissipation (T
A
= +70°C)
40-Pin Thin QFN 6mm x 6mm x 0.8mm
(derated 26.3mW/°C above +70°C)........................2105.3mW
Operating Temperature Range ...........................-40°C to +85°C
Junction Temperature ......................................................+150°C
Storage Temperature Range .............................-65°C to +150°C
Lead Temperature (soldering 10s) ..................................+300°C
ELECTRICAL CHARACTERISTICS
(V
DD
= 3.3V, OV
DD
= 2.0V, GND = 0, REFIN = REFOUT (internal reference), C
REFOUT
= 0.1µF, C
L
≈ 5pF at digital outputs, V
IN
=
-0.5dBFS, CLKTYP = high, DCE = high, PD = low, G/T = low, f
CLK
= 65MHz (50% duty cycle), C
REFP
= C
REFN
= 0.1µF to GND, 1µF
in parallel with 10µF between REFP and REFN, C
COM
= 0.1µF in parallel with 2.2µF to GND, T
A
= -40°C to +85°C, unless otherwise
noted. Typical values are at T
A
= +25°C.) (Note 1)
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
DC ACCURACY
Resolution
12
Bits
Integral Nonlinearity
INL
f
IN
= 20MHz (Note 2)
±0.4
±0.7
LSB
Differential Nonlinearity
DNL
f
IN
= 20MHz, no missing codes over
temperature (Note 2)
±0.3
±0.7
LSB
Offset Error
V
REFIN
= 2.048V
±0.2
±0.9
%FS
Gain Error
V
REFIN
= 2.048V
±0.3
±4.9
%FS
ANALOG INPUT (INP, INN)
Differential Input Voltage Range
V
DIFF
Differential or single-ended inputs
±1.024
V
Common-Mode Input Voltage
V
DD
/ 2
V
Input Resistance
R
IN
Switched capacitor load
15
kΩ
Input Capacitance
C
IN
4
pF
CONVERSION RATE
Maximum Clock Frequency
f
CLK
65
MHz
Minimum Clock Frequency
5
MHz
Data Latency
Figure 5
8.5
Clock
cycles
DYNAMIC CHARACTERISTICS (Differential inputs, 4096-point FFT)
f
IN
= 3MHz at -0.5dBFS
68.5
Signal-to-Noise Ratio
SNR
f
IN
= 32.5MHz at -0.5dBFS (Note 2)
67.1
68.5
dB
f
IN
= 3MHz at -0.5dBFS
68.4
Signal-to-Noise and Distortion
SINAD
f
IN
= 32.5MHz at -0.5dBFS (Note 2)
67.0
68.4
dB
f
IN
= 3MHz at -0.5dBFS
90.4
Single-Tone Spurious-Free
Dynamic Range
SFDR
f
IN
= 32.5MHz at -0.5dBFS (Note 2)
82.2
88.7
dBc
f
IN
= 3MHz at -0.5dBFS
-89.3
Total Harmonic Distortion
THD
f
IN
= 32.5MHz at -0.5dBFS (Note 2)
-86.4
-80.7
dBc
