Relative Accuracy (Note 2)
MAX186/MAX188
Low-Power, 8-Channel,
Serial 12-Bit ADCs
2 _______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL CHARACTERISTICS
(V DD = 5V ±5%; V SS = 0V or -5V; f CLK = 2.0MHz, external clock (50% duty cycle); 15 clocks/conversion cycle (133ksps); MAX186—
4.7µF capacitor at VREF pin; MAX188—external reference, VREF = 4.096V applied to VREF pin; T A = T MIN to T MAX , unless otherwise
noted.)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
PARAMETER SYMBOL MIN TYP MAX UNITS
±1.0
LSB
±0.75
±1.0
±0.5
Differential Nonlinearity DNL ±1 LSB
±2.0
±3.0
±3.0
Resolution 12 Bits
±0.5
Offset Error
±3.0
LSB
±3.0
±1.5
±2.0
±2.0
Gain Error (Note 3)
±3.0
LSB
Gain Temperature Coefficient ±0.8 ppm/°C
±0.1 LSB
SINAD 70 dB
THD -80 dB
Spurious-Free Dynamic Range SFDR 80 dB
Channel-to-Channel Crosstalk -85 dB
CONDITIONS
MAX186D/MAX188D
MAX186D/MAX188D
MAX186 (all grades)
MAX188C
MAX186C
MAX186B/MAX188B
No missing codes over temperature
MAX186A/MAX188A
MAX186B/MAX188B
MAX186C/MAX188C
External reference
4.096V (MAX188)
External reference, 4.096V
MAX186A/MAX188A
65kHz, V
IN
= 4.096V
P-P
(Note 4)
V DD to AGND............................................................-0.3V to +6V
V SS to AGND ............................................................+0.3V to -6V
V DD to V SS ..............................................................-0.3V to +12V
AGND to DGND.....................................................-0.3V to +0.3V
CH0–CH7 to AGND, DGND .............(V
SS - 0.3V) to (V DD + 0.3V)
CH0–CH7 Total Input Current ..........................................±20mA
VREF to AGND ...........................................-0.3V to (V
DD + 0.3V)
REFADJ to AGND.......................................-0.3V to (V DD + 0.3V)
Digital Inputs to DGND...............................-0.3V to (V DD + 0.3V)
Digital Outputs to DGND ............................-0.3V to (V DD + 0.3V)
Digital Output Sink Current .................................................25mA
Continuous Power Dissipation (T A = +70°C)
Plastic DIP (derate 11.11mW/°C above +70°C) ...........889mW
SO (derate 10.00mW/°C above +70°C) ........................800mW
SSOP (derate 8.00mW/°C above +70°C) .....................640mW
CERDIP (derate 11.11mW/°C above +70°C) ................889mW
Operating Temperature Ranges:
MAX186_C/MAX188_C ........................................0°C to +70°C
MAX186_E/MAX188_E......................................-40°C to +85°C
MAX186_M/MAX188_M ..................................-55°C to +125°C
Storage Temperature Range .............................-60°C to +150°C
Lead Temperature (soldering, 10sec) .............................+300°C
MAX188A
MAX188B
MAX188C
MAX188D
Channel-to-Channel
Offset Matching
Signal-to-Noise + Distortion Ratio
Total Harmonic Distortion
(up to the 5th harmonic)
DC ACCURACY (Note 1)
DYNAMIC SPECIFICATIONS (10kHz sine wave input, 4.096V P-P , 133ksps, 2.0MHz external clock, bipolar input mode)
