21
AT77C101B
2150A–BIOM–02/02
Figure 18. Product Reference: FCD4B14CC (For Development Only)
0.08
0.75 max
3.15 ± 0.32
0.81 ± 0.05
0.46 ± 0.05
0.25 max
1.1 ± 0.1
2.54 ± 0.13
22.86 ± 0.13
4.75 ± 0.1
60°
0.08
25.4 ± 0.25
9.36 ± 0.15 6.34 ± 0.15
0.1 min
(2.45)
(0.90)
NO.1
NO.10
NO.20 NO.11
(0.20) 5.4 max
7.5 ± 0.25
7.87 ± 0.25
0.25 ± 0.05
(7.62)
6.5 max
DIL (all dimensions in mm)
