20
AT77C101B
2150A–BIOM–02/02
Figure 17. Product reference: AT77C101B-CB02C
5.9 max
9.85 ± 0.3
4.1 ± 0.2
FLEX OUTPUT
5.2 max
8.9 ± 0.5
8.8 ± 0.2
1.25 ± 0.5
26.6 ± 0.3
0.75
+0.33
-0.25
2.39 ± 0.5
0.8 MAX
4.1 ± 0.5
6.3 ± 0.1
1.78 ± 0.5 (x 2)
FLEX OUTPUT
R0.75
+0.08
-0.12 (x 3)
All dimensions in mm
2.9 ± 0.5
0.2 min
1.9 ± 0.4
0.83 ± 0.11
COUPE AA
1.5 MAX
14.35
+0.04
-0.01
1.5
+0.15 -0.23
(x 3)
1.66
+0.07 -0.01
