ADIS16250/ADIS16255
Rev. B | Page 20 of 20
OUTLINE DIMENSIONS
02
20
07-
B
SIDE VIEW
TOP VIEW BOTTOM VIEW
PIN 1
INDICATOR
1.000 BSC
(20×)
5.50
MAX
11.00
TYP
1
5
6 10
11
15
16 20
11.15
MAX
7.600
BSC
(4×) 3.800
BSC
(8×)
7.00
TYP
10.173
BSC
(2×)
0.200
MIN
(ALL SIDES)
0.900 BSC
(16×)
0.373 BSC
(20×)
Figure 24. 20-Terminal Stacked Land Grid Array [LGA]
(CC-20-1)
Dimensions shown in millimeters
ORDERING GUIDE
Model Temperature Range Package Description Package Option
ADIS16250ACCZ 1 −40°C to +85°C 20-Terminal Stacked Land Grid Array [LGA] CC-20-1
ADIS16255ACCZ 1 −40°C to +85°C 20-Terminal Stacked Land Grid Array [LGA] CC-20-1
ADIS16250/PCBZ 1 Evaluation Board for the ADIS16250
ADIS16255/PCBZ 1 Evaluation Board for the ADIS16255
1 Z = RoHS Compliant Part.
©2006–2007 Analog Devices, Inc. All rights reserved. Trademarks and
registered trademarks are the property of their respective owners.
D06070-0-3/07(B)
