78M6631 Data Sheet DS_6631_056
18 Rev 1
2.4.4 Power Supply Monitor
Table 8: Power Supply Monitor Performance Specifications (BME= 1)
Parameter Condition Min Typ Max Unit
Load Resistor – 27 45 63 kΩ
LSB Value
[M40MHZ, M26MHZ]
= [00], [10], or [11]
FIR_LEN=0(L=138)
FIR_LEN=1(L=288)
(-10%) -48.7
-5.35
(+10%) µ V
µ V
[M40MHZ, M26MHZ]
= [01]
FIR_LEN=0(L=186)
FIR_LEN=1(L=384)
(-10%) -19.8
-2.26
(+10%) µ V
µ V
Offset Error -200 0 +100 mV
2.4.5 Supply Current
Table 9: Supply Current Performance Specifications
Parameter Condition Min Typ Max Unit
V3P3D current (CE off) Normal Operation,
V3P3A = V3P3SYS = 3.3 V
CKMPU = 614 kHz
No flash memory write
RTM_E=0, ECK_DIS=1,
ADC_E=1, ICE_E=0
4.2 6.35 mA
V3P3D current (CE on) 8.4 9.6 mA
V3P3A current 3.3 3.8 mA
V3P3D current,
Write Flash Normal operation as above, except
write flash at maximum rate, CE_E =
0, ADC_ E = 0
9.1 12 mA
2.4.6 Crystal Oscillator
Table 10: Crystal Oscillator Performance Specifications
Parameter Condition Min Typ Max Unit
Maximum Output Power to Crystal 4 Crystal connected 1 µ W
XIN to XOUT Capacitance 1 3 pF
Capacitance to DGND 1
XIN
XOUT
RTCA_ADJ = 0
5
5
pF
pF
