Protocols & Firmware
Bluetooth Stack V2.0 compliant. Fully integrated.
Profiles GAP (Generic Access Profile)
SDP (Service Discovery Profile)
SPP (Serial Port Profile)
FTP Client
Advertised Profiles DUN (Dial Up Networking)
FTP Server
Headset (Audio Gateway)
Handsfree (Audio Gateway)
Profile Components Audio Gateway
Generic OBEX Push/Pull Client
Firmware Upgrade Available over UART
Connection Modes Point to point (cable replacement)
Multipoint – max 7 slaves
Command Interface
AT Instructions set Comprehensive control of connection and module operation
S Registers for non-volatile storage of parameters
Multipoint Software Supports multiple connections
Current Consumption
Data Transfer Typically 130mA
Low Power Sniff Mode Less than 2.5mA
Supply Voltage
Supply 3.6V – 5.0V DC
(For 3.3V operation see BTM404)
Regulation On-board regulators and brown-out detection
Coexistence / Compatibility
WLAN (802.11) 2-wire and 3-wire hardware coexistence schemes supported
Pin compatible with EZURiO WISM Bluetooth modules
Connections
Interface 40 way Hirose DF-12 Connector
External Antenna (option) U.FL connector for 50 Ohm antenna
Physical
Dimensions 22.8mm x 33.8mm x 7.6mm
Weight 8 grams
Environmental
Operating Temperature Continuous transmission: -10°C to +85°C
Storage Temperature -40°C to +85°C
Approvals
Bluetooth Qualified as an END product B0xxxx
FCC Modular Approval PI408B
IC Industry Canada 1931B-BISMPA
CE & R&TTE Approved
Miscellaneous
Lead free Lead-free and RoHS compliant
Warranty 2 Years
Development Tools
Development Kit Development board and software tools
† DSR, DTR, RI and DCD are configurable either as GPIO or as modem control lines.
