www.EZURiO.com
DSH_BTM402_0v9 BISM2 PA Data Sheet.DOC © 2007 EZURiO Ltd 2
1.1 Applications
• POS Equipment
• Medical Equipment
• Telematics
• Voice Applications
• Industrial Automation
• Automotive Applications
2. Features
Feature Implementation
Wireless Specification
Standards Supported Bluetooth v2.0
Transmit Class Class 1
Frequency 2.400 – 2.4835 GHz
Channels 79 channels Frequency Hopping
Adaptive Frequency Hopping
Max Transmit Power +18 dBmi from integrated antenna
+16 dBm @ antenna connector (option)
Min Transmit Power -27 dBmi from integrated antenna
Receive Sensitivity -87 dBm
Data Transfer rate Up to 300kbps
Range Up to 1,000 metres free space
Antenna Modes
Integrated Antenna High performance +2dBi multilayer ceramic
External Antenna (option) 50 Ohm U.FL connection
UART Interface
Serial Interface RS-232 bi-directional for commands and data
16550 compatible
Baud Rate Configurable from 1,200 to 921,600bps
Non-standard baud rates supported
Bits 7 or 8
Parity Odd, even, none
Stop bits 1 or 2
Default Serial parameters 9,600,n,8,1
Levels 3.3V CMOS
Modem Control DTR, DSR, DCD, RI, RTS, CTS †
General Purpose Interface
I/O 7 general purpose I/O pins, 3.3V CMOS †
ADC 2 ADC inputs. 8 bit, 1.8V max
Audio
Support 3 PCM Channels @ 64kbps
SCO Channels Support SCO and eSCO
PCM Interface Configurable as master or slave
8 bit A-law
8 bit μ-law
13 bit linear
PCM Clock available when in slave mode
