Rainbow Electronics DAB-WLS-C21 (BlueTooth) - Manual (Page 27)

www.EZURiO.com
DSH_BTM402_0v9 BISM2 PA Data Sheet.DOC © 2007 EZURiO Ltd 27
13. Environmental
13.1 Operating temperatures
ture
ility
Parameter Min Typ Max Unit
Operating temp (standard product) -10 25 +85 °C
13.2 Storage tempera
Parameter Min Max
13.3 Reliab
Parameter
Unit
Storage temp -40 +85
Test Comment
Thermal Shock 200 cycles -20ºC /+65ºC 30 min 1 cycle/hour
Vibration Continuous operation at 60 Hz,
2mm stroke
15g max sine wave, 12 hours
Shock 50G 11ms Half Sine Wave 6 axis x 3 cycles each axis
Moisture Resistance
High Temp Storage 80ºC, 360 hours
Low Temp Storage -20ºC, 240 hours
High Temp/Humidity
Operation
60ºC, 90%RH, 360 hours
Thermal shock -20 to 60ºC in 30min 200 cycles with continuous
operation
Electro Static Discharge EN55024:1998 & IEC61000-4-3
Drop Test 75cm to concrete, 3 axis x 2
cycles per corner
°C
