AT77C105A [Preliminary]
5419A–BIOM–01/05
Specifications
Table 2. Absolute Maximum Ratings
Parameter
Symbol
Comments
Value
Power supply voltage
VDDD, VDDA
-0.5 to 4.6V
Note: Stresses beyond those listed
under “Absolute Maximum
Ratings” may cause permanent
damage to the device. These are
stress ratings only and functional
operation of the device at these or
any other conditions beyond those
indicated in the operational
sections of this specification is not
implied. Exposure to absolute
maximum rating conditions for
extended periods may affect device
reliability.
Front plane
FPL
GND to V
DD
+0.5V
Digital input
SSS, FSS,
SCK, MOSI
GND to V
DD
+0.5V
Input/output pads power
supply
VDD_IO
GND to V
DD
+0.5V
Storage temperature
T
stg
-50 to +95
°C
Lead temperature
(soldering 10 seconds)
T
leads
Do not solder
Forbidden
Table 3. Recommended Conditions of Use
Parameter
Symbol
Comments
Min
Typ
Max
Unit
Positive supply voltage
V
DD
2.5 ±5%
3.3 ±10%
2.3
2.5
3.3
3.6
V
Front plane
FPL
Must be grounded
GND
V
Digital input voltage
CMOS levels
V
Digital output voltage
CMOS levels
V
Digital load
C
L
20
50
pF
Operating temperature range
T
amb
Industrial “V” grade
-40 to +85
°C
Maximum current on VDDA
IVDDA
0
-
60
mA
Table 4. Resistance
Parameter
Min Value
Standard Method
ESD
On pins HBM (Human Body Model) CMOS I/O
2 kV (TBC)
MIL-STD-883 method 3015.7
On die surface (zap gun) air discharge
±16 kV
(TBC)
NF EN 6100-4-2
Mechanical Abrasion
Number of cycles without lubricant
Multiply by a factor of 20 for correlation with a real finger
200 000
MIL E 12397B
Chemical Resistance
Cleaning agent, acid, grease, alcohol, diluted acetone
4 hours
Internal method
