ATMOS -2M60/2M30 [Preliminary]
1. Typical Performances
Note: 1. Measured with light source 3200
°K and BG38 IR cut-off filter 2 mm thickness.
Table 1-1. Camera Typical Performances
Sensor Characteristics at Maximum Pixel Rate
2M60 2M30 Unit
Resolution H × V 2096 Ч 1184 2096 Ч 1184 Pixels
Pixel size (square) 5 Ч 5 5 Ч 5 µm
Maximum frame rate 48 24 Hz
Pixel rate 150 75 MHz
Camera Performances
Bit depth 8, 10 or 12 Bits
Spectral range 350–1000 nm
Linearity ±2% in 5% and 95% of FSR
PRNU 1.5% rms
FPN 0.1% rms
Peak Response @ G = 0 33 (1) LSB/nJ/cm 2
Output RMS Noise
Dynamic range
< 3 LSB rms
> 62.5
dB
Conversion factor 11 e - / LSB
Dark Current 1500 e - /s
Over Illumination Behavior 75 Esat
Mechanical and Electrical Interface
Size (w × h × l) 44 Ч 44 Ч 45 mm
Weight 115 g
Lens Mount C-mount
Sensor Alignment
∆x, y = ± 250
∆z = ±150
∆0
xy
= ± 0.7
∆tilt
z
= 0-200
µm
µm
degree
µm
Power supply single 12 to 24 VDC
Power consumption < 3 W
Operating temperature 0 to 55 (non-condensing) °C
Storage temperature -40 to 70 °C
